Description
The HDMI Ultra-Slim HDBaseT + RS232 And IR over Cat Extender Box Receiver - 4K 60Hz allows a 4K HDMI source to be extended up to 130ft to a 4K display using a single Cat6a Ethernet cable. This is an ideal solution where HDMI video and audio need to be extended to displays in conference rooms, classrooms, lecture halls, and many other installation needs that are far beyond the length limitations of standard HDMI cabling.
This wall plate transmitter and box receiver accepts HDMI signals over a single network patch cable. Extend 4K HDMI up to 115 feet and 1080p up to 230 feet using a Cat5e or Cat6 cable. For longer 4K distances, extend 4K HDMI or up to 130 feet using a Cat6a cable.
This HDMI HDBaseT set is HDCP 2.2 compliant, making sure that the connection from the source is secure. With bi-directional PoC support, one power adapter at either transmitter or receiver side can power both units, so no additional power adapter is required, allowing for greater flexibility in installations. Advanced users can control bi-directional IR and RS232 pass through.
This wall plate transmitter and box receiver accepts HDMI signals over a single network patch cable. Extend 4K HDMI up to 115 feet and 1080p up to 230 feet using a Cat5e or Cat6 cable. For longer 4K distances, extend 4K HDMI or up to 130 feet using a Cat6a cable.
This HDMI HDBaseT set is HDCP 2.2 compliant, making sure that the connection from the source is secure. With bi-directional PoC support, one power adapter at either transmitter or receiver side can power both units, so no additional power adapter is required, allowing for greater flexibility in installations. Advanced users can control bi-directional IR and RS232 pass through.
- Extend 4K at 60Hz (4:2:0) up to 130ft and 1080p at 60Hz up to 230ft with Cat 6a cable
- Extend 4K at 60Hz (4:2:0) up to 115ft and 1080p at 60Hz up to 200ft with Cat 5e/6 cable
- HDCP 2.2 compliant, to create a secure connection between the source and display
- Number of VGA Inputs : 1
- Supported Video Modes : 1080p
- Number of HDMI Outputs : 1
- Maximum Operating Distance : 230 ft (70104 mm)
- Number of Input Devices Supported : 2
- Transmitter Depth : 3.70" (94 mm)
- Number of Output Devices Supported : 1
- Package Contents :
- 1 x Transmitter Unit
- 1 x Receiver Unit
- Manufacturer Website Address : http://www.cablestogo.ca
- Number of USB Ports : 1
- Receiver Width : 4.28" (108.80 mm)
- HDMI Out : Yes
- Twisted Pair Cable Standard : Category 7
- Manufacturer : C2G
- Transmitter Height : 0.79" (20 mm)
- Receiver Height : 0.59" (15 mm)
- USB : Yes
- HDMI In : Yes
- Product Color : Black
- Receiver Depth : 2.53" (64.20 mm)
- VGA In : Yes
- Network (RJ-45) : Yes
- Number of HDMI Inputs : 2
- Product Type : Video Extender Transmitter/Receiver
- Graphics Modes : 4K
- Transmitter Width : 7.67" (194.70 mm)
- Media Type Supported : Twisted Pair
- Country of Origin : China
- Number of Network (RJ-45) Ports : 2
- Connectivity Technology : Wired
