QNAP TS-1277 Système de stockage SAN/NAS TS-1277-1700-64G-US

TS-1277

The first Ryzen™-based NAS with up to 8 cores and 16 threads and graphics card support to redefine your virtualization and 4K processing experiences

The TS-1277 powered by AMD's new 14nm Ryzen™ processor redefines the high-end desktop business NAS for greater video and virtual machine performance with up to 8 cores/16 threads native processing and Turbo Core up to 3.7 GHz. Cutting-edge hardware integrated with multitasking software makes the TS-1277 the preeminent choice to tackle resource-demanding applications and tasks.

Two M.2 SATA 6Gb/s SSD slots for caching or caching pools to accelerate system performance.

PCIe expandability allows for 10GbE/40GbE adapters, PCIe NVMe SSD, graphics cards, USB 3.1 10Gbps cards, or wireless network cards.

Supports AMD Radeon™ and NVIDIA® graphics cards for video processing or GPU-passthrough to VMs.

Qtier™ technology and SSD caching enable 24/7 optimized storage efficiency.

Scalable storage supporting virtualization, containerized apps, centralized storage, backup, sharing, and disaster recovery.

RAID 50/60 is recommended for NAS with over 10 disks to strike a balance between capacity, protection, and performance.

Absolute performance with AMD Ryzen™ and up to 64GB RAM

Powered by a high-performance AMD Ryzen™ 7 1700 or AMD Ryzen™ 5 1600 processor with AES-NI encryption acceleration and up to 64GB DDR4 RAM, the TS-1277 delivers aggressive yet power-smart performance to meet your multitasking demands and is capable of running up to 16 virtual machines simultaneously*. For resource-demanding business applications such as VDI, R&D, private cloud, and server virtualization, the TS-1277 with gold-standard performance is your ideal choice.

Top-class hardware engineering

The feature-packed hardware of the TS-1277 bolsters overall system performance. Coupled with the flexible and expandable architecture, the TS-1277 fulfills diversified application needs.

Extend NAS functionality with PCIe slots

The TS-1277 features three PCIe slots (1 x PCIe 3.0 x8, 1 x PCIe 3.0 x4, 1 x PCIe 2.0 x4) that allow for installing 10GbE/40GbE network cards, QM2 M.2 SSD/10GbE PCIe cards, or compatible wireless network cards for greater application potential.

Fuel GPU-accelerated computing with a 550W power supply

Graphics cards are optimized for graphical calculations and transformations, but require significantly more power compared to other hardware. The TS-1277 offers PCIe slots to support AMD Radeon™ or NVIDIA® graphics cards and a 550 watt power supply that is capable of powering a graphics card for boosting imaging processing in QTS and performance of virtual machines via GPU passthrough. When enjoying videos with the TS-1277, you can use the remote control (RM-IR004, optional purchase) that supports QButton for a more convenient control of your multimedia experience.

• Perform computational tasks effectively accrediting the amd ryzen 7 3 ghz processor
• Up to 10x faster than standard Ethernet connectivity and provides high-performance uplinks
• Through RAID levels (0, 1, 5, 6, 10, 50, 60, hot spare, jbod), RAID provides data reliability, fault tolerance and improves overall performance

• Memory Technology : DDR4 SDRAM
• Standard Memory : 64 GB
• Manufacturer Website Address : http://www.qnap.com
• Flash Memory Capacity : 512 MB
• Number of Total Expansion Bays : 12
• Processor Core : Octa-core (8 Core)
• Processor Manufacturer : AMD
• Number of 2.5" Bays : 4
• Product Series : TS-x77
• Controller Type : Serial ATA/600
• RAID Supported : Yes
• Operating System : QTS 4.3
• Processor Type : Ryzen 7
• Number of Solid State Drive Supported : 4
• Number of Solid State Drive Installed : No
• Package Contents :
  • TS-1277 SAN/NAS Storage System
  • 2 x Ethernet Cables
  • Quick Installation Guide (QIG)
  • Flat Head Screws (For 2.5" HDD)
  • Flat Head Screw (For M.2 SSD)
  • 1 x Power Cord
  • 2 x M.2 SSD Cooling Module
• Protocols : DNS,Telnet,DLNA,IPv6,FTPS,WEBDAV,SSL/TLS,AFP,CIFS,HTTPS,FTP,SSH,DHCP,SMTP,FXP,LDAP,iSCSI,IPv4,UPnP,PPTP,TCP/IP,HTTP,DDNS,CIFS/SMB,SNMP,RSync
• RAID Levels : 0, 1, 5, 6, 10, 50, 60, Hot Spare, JBOD
• Number of Hard Drives Supported : 12
• Number of Hard Drives Installed : No
• Number of Total Expansion Slots : 3
• Form Factor : Tower
• Manufacturer : QNAP Systems
• Number of USB 3.0 Ports : 6
• Product Type : SAN/NAS Storage System
• Limited Warranty : 2 Year
• Number of 3.5" Bays : 8
• Ethernet Technology : Gigabit Ethernet
• Product Model : TS-1277
• Network (RJ-45) : Yes
• HDMI : Yes
• Processor Model : 1700
• Processor Speed : 3 GHz
• Total Number of USB Ports : 8
