Description
TS-464U
Intel® quad-core rackmount NAS with dual-port 2.5GbE and PCIe expandability for high-speed transmission and virtualization applications
Powered by an Intel® Celeron® N5105/N5095, quad-core processor (burst up to 2.9GHz), the TS-464U features two 2.5GbE RJ45 ports and Port Trunking for up to 5Gbps combine bandwidth. The built-in 4K HDMI output allows for multimedia and virtual machine display. With a PCIe Gen 3 slot, the TS-464U provides flexibility in extending NAS functionality, allowing you to install various cards: 10GbE/5GbE network card, QM2 card for M.2 SSD caching, or Edge TPU for AI image recognition. The TS-464U also supports AES 256-bit encryption to ensure the confidentiality of sensitive business data without affecting system performance.
-
2.5GbE connectivity
Up to 5 Gbps transfer speeds can be achieved by setting port trunking with the two built-in 2.5GbE (2.5G/1G/100M) ports.
-
PCIe expandability
Install a PCIe Gen3 x2 card to expand the core functionality of the TS-464U, including a Multi-Gig 10GbE/5GbE/2.5GbE network card, a QM2 card, or a USB 3.2 Gen 2 (10Gbps) card.
-
Snapshots
Protect your files and data from accidental deletion and malware attacks with snapshots that fully record the system status and data.
-
License-free virtualized environment
Host multiple containerized apps to run a wide range of applications and services.
-
Drives Auto-Tiering
Qtier™ auto-tiering technology and SSD caching enable constant storage optimization.
-
Flexible expansion
Scale your storage capacity to fit growing data needs by connecting QNAP's expansion units.
Quad-core high performance and up to 16GB RAM
The TS-464U is powered by an Intel Celeron N5105 / N5095 quad-core processor and supports up to 16 GB DDR4 memory, two 2.5GbE ports and SATA 6 Gb/s drives. The integrated Intel® AES-NI encryption engine also helps protect confidential data without impacting system performance.
Streamline large file transfers and video editing with 2.5GbE
The TS-464U comes with two 2.5GbE RJ45 (2.5G/1G/100M) LAN ports that allow you to use existing CAT5e cables to upgrade network speeds from 1 Gigabit to 2.5 Gigabit. The dual 2.5GbE ports also support Port Trunking for up to 5 Gbps transmission speeds, improving the efficiency of bandwidth-hungry business applications such as large file transfers, fast backup/restore, and multimedia transfer & editing.
Future-proof your IT infrastructure for high-speed networks
The TS-464U is ideally matched with QNAP's managed and unmanaged 2.5GbE/10GbE switches to form high-speed, secure, and scalable network environments without going over budget. QNAP also provide 2.5GbE/5GbE/10GbE PCIe cards and USB 5GbE adapters for Windows®/Linux® workstations, allowing you to easily build a high-speed network environment for productive team collaboration.
. .- Protocols : LDAP,HTTPS,L2TP,SFTP,DHCP,WEBDAV,SNMPv2,SSH,IPSec,FTPS,AFP,FTP,CIFS/SMB,IPv4,Telnet,SSL,iSCSI,TLS,NFS,HTTP,TFTP,FXP,DDNS,IPv6,PPTP
- Flash Memory Capacity : 4 GB
- Maximum Power Supply Wattage : 250 W
- Number of Hard Drives Installed : 0
- Controller Type : Serial ATA/600
- Number of USB 2.0 Ports : 2
- Total Number of USB Ports : 4
- Processor Type : Celeron
- Processor Core : Quad-core (4 Core)
- RAID Supported : Yes
- Form Factor : Rack-mountable
- Memory Technology : DDR4 SDRAM
- Package Contents :
- TS-464U-8G SAN/NAS Storage System
- 1 x Ethernet Cable
- 2 x Power Cords
- 48 x Flat Head Screws (for 3.5" HDD)
- 36 x Flat head screws (for 2.5" HDD)
- 2 x Hanger
- Quick Installation Guide (QIG)
- Manufacturer Website Address : http://www.qnap.com
- Processor Manufacturer : Intel
- Number of Solid State Drive Installed : 0
- Number of Power Supplies Installed : 1
- Manufacturer : QNAP Systems
- Product Model : TS-464U-8G
- Number of Total Expansion Bays : 4
- Operating System : QTS 5.0.1
- RAID Levels : 0, 1, 5, 6, 10, JBOD
- Rack Height : 1U
- Standard Memory : 8 GB
- Ethernet Technology : 2.5 Gigabit Ethernet
- Number of Hard Drives Supported : 4
- Additional Warranty Information : The TS-464U is backed by a 3-year warranty at no additional cost.
- Number of 2.5"/3.5" Bays : 4
- Number of USB 3.2 Gen 2 Ports : 2
- Number of Solid State Drive Supported : 4
- Limited Warranty : 3 Year
- Network (RJ-45) : Yes
- Product Type : SAN/NAS Storage System
- Number of Total Expansion Slots : 1
- HDMI : Yes
- Number of Network (RJ-45) Ports : 2
- Expansion Slot Type : PCI Express 3.0 x2
