QNAP Turbo NAS TS-264-8G Système de stockage SAN/NAS TS-264-8G-US

TS-264 | Intel quad-core dual-port 2.5GbE NAS supports M.2 SSD caching and PCIe expandability for high-speed transmission and virtualization applications

Powered by an Intel® Celeron® N5095, quad-core processor (burst up to 2.9GHz), the TS-264 features two 2.5GbE RJ45 ports and Port Trunking for up to 5Gbps combined bandwidth. With M.2 PCIe Gen3 and PCIe Gen 3 slots, the TS-264 provides flexibility in extending NAS functionality, allowing you to install a QM2 card for M.2 SSD caching, or Edge TPU for AI image recognition and various 10GbE/5GbE network cards. The TS-264 comes with 8 GB RAM for running light VMs and Containers, and supports multi-cloud backup, cloud storage gateways, 4K HDMI output and real-time transcoding, alongside expandable storage capacity and feature-rich apps to perform as a cost-efficient, reliable 2.5GbE NAS.

2.5GbE port

Up to 5 Gbps transfer speeds can be achieved by setting port trunking with the two built-in 2.5GbE (2.5G/1G/100M) ports.

M.2 SSD caching

Dual M.2 PCIe Gen 3 slots enable NVMe SSD caching or SSD storage pools for improved performance, or Edge TPU for AI image recognition.

PCIe expandability

Install a PCIe Gen3 x2 card to expand the core functionality of the TS-264, including a Multi-Gig 10GbE/5GbE/2.5GbE network card, a QM2 card, or a USB 3.2 Gen 2 (10Gbps) card.

License-free virtualized environment

Host multiple containerized apps to run a wide range of applications and services.

Drives Auto-Tiering

Qtier™ auto-tiering technology and SSD caching enable constant storage optimization.

4K HDMI

4K H.264 hardware decoding and real-time transcoding for smooth big screen multimedia experience.

Quad-core high performance and up to 8 GB RAM

The TS-264 is powered by an Intel Celeron N5095 quad-core processor and supports up to 8 GB DDR4 memory, two 2.5GbE ports and SATA 6 Gb/s drives. The integrated Intel® AES-NI encryption engine also helps protect confidential data without impacting system performance.

Accelerate AI-powered image recognition and caching with TPU and PCIe expansion

The TS-264 has two M.2 PCIe Gen3 slots, enabling SSD caching or SSD storage pools for improved performance, or Edge TPU for AI image recognition.

Install M.2 NVMe SSDs for cache acceleration or efficient tiered storage

The TS-264 supports SSD caching and features two M.2 slots that support M.2 PCIe NVMe SSDs with 2280 form factors (sold separately) for boosting overall NAS performance. Qtier™ technology can also be used to empower the TS-264 with auto tiering that helps continuously optimize storage efficiency across all installed storage devices.

. .

• Protocols : IPv4,IPv6,DHCP,CIFS/SMB,AFP,NFSv3,FTP,FTPS,SFTP,TFTP,HTTP,HTTPS,Telnet,SSH,iSCSI,SNMP,SSL/TLS,FXP,WEBDAV,LDAP,DDNS,DNS,SNMPv2,SNMPv3,PPTP,L2TP,NFSv4
• Flash Memory Capacity : 4 GB
• Number of Processors Installed : 1
• Maximum Power Supply Wattage : 65 W
• Number of Hard Drives Installed : 0
• Controller Type : Serial ATA/600
• Product Series : TS-x62
• Number of USB 2.0 Ports : 2
• Total Number of USB Ports : 4
• Processor Type : Celeron
• Processor Core : Quad-core (4 Core)
• RAID Supported : Yes
• Form Factor : Tower
• Memory Technology : DDR4 SDRAM
• Package Contents :
  • Turbo NAS TS-264-8G SAN/NAS Storage System
  • 1 x Ethernet Cable
  • 1 x Power Cord
  • 36 x Flat head screw (for 3.5" HDD)
  • 36 x Flat head screw (for 2.5" HDD)
  • AC Adapter
• Manufacturer Website Address : http://www.qnap.com
• Processor Manufacturer : Intel
• Number of Solid State Drive Installed : 0
• Manufacturer : QNAP Systems
• Product Model : TS-264-8G
• Processor Model : N5095
• Number of Total Expansion Bays : 2
• Operating System : QTS 5.0.1
• RAID Levels : 0, 1, JBOD
• Standard Memory : 8 GB
• Ethernet Technology : 2.5 Gigabit Ethernet
• Number of Hard Drives Supported : 2
• Additional Warranty Information : The TS-264 is backed by a 3-year warranty at no additional cost.
• Number of 2.5"/3.5" Bays : 2
• Number of USB 3.2 Gen 2 Ports : 2
• Number of Solid State Drive Supported : 2
• Limited Warranty : 3 Year
• Network (RJ-45) : Yes
• Product Type : SAN/NAS Storage System
• Number of Total Expansion Slots : 1
• HDMI : Yes
• Number of Network (RJ-45) Ports : 2
• Product Line : Turbo NAS
• Expansion Slot Type : PCI Express 3.0 x2
