Ubiquiti 48 Port Switch - USW-PRO-MAX-48

Economisez $60.14
UbiquitiSKU: USW-PRO-MAX-48

Prix:
Prix réduit$916.99 Prix normal$977.13
Stock:
Plus que 44 en stock

Récupération disponible à DeployDepot.ca

Habituellement prête en 24 heures

Estimer la livraison

Description

A 48-port, Layer 3 Etherlighting switch with 2.5 GbE. Etherlighting ports that illuminate to indicate port location, speed/link, and native VLAN/network* (16) 2.5 GbE RJ45 ports (32) GbE RJ45 ports (4) 10G SFP+ ports DC power backup ready Managed with UniFi Network 8.0.24 and later



Overview
Dimensions
442 x 325 x 44 mm
(17.4 x 12.8 x 1.7")
Port Layout


1 GbE RJ45
32


2.5 GbE RJ45
16


10G SFP+
4
Redundancy
DC Power Backup
Layer 3
Yes
Form Factor
Rack Mount (1U)
Etherlighting™
Yes

Performance
Switching Capacity
224 Gbps
Total Non-Blocking Throughput
112 Gbps
Forwarding Rate
167 Mpps
Supported VLANs
1,000
MAC Address Table Size
32,000
L3 Table Size


ARP Entries
12,000


IPv4 Routes
12,000
Packet Buffer Size
2 MB

Layer 3 Features
DHCP Server (Local Networks)
Yes
DHCP Relay
Yes
Inter-VLAN Routing (Local Networks)
Yes
Static Routing (Local Networks)
Yes

Layer 2 Features
LACP Port Aggregation
Yes
STP & RSTP
Yes
QoS (DSCP)
Yes
Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)
Yes
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
Yes
IGMP Snooping
Yes
802.1X Control
Yes
MAC-Based ACLs & Device Isolation
Yes
DHCP Snooping & Guarding
Yes
Egress Rate Limit
Yes
Flow Control
Yes
Storm Control
Yes
Multicast & Broadcast Rate Limiting
Yes
MAC Address Blocking
Yes
IP-Based ACLs & Network Isolation
Yes
MAC-Based Port Restriction
Yes
Port Isolation
Yes
Port Mirroring
Yes
Jumbo Frames
Yes
LLDP-MED
Yes
Voice VLAN
Yes
Loop Protection
Yes

Hardware
Max. Power Consumption
100W
Power Method
(1) Universal input, 100—240V AC, 50/60 Hz
(1) USP RPS DC input
Power Input Method
AC input
Power Supply
AC/DC, internal, 100W
Supported Voltage Range
100—240V AC
Supported Rack Depth
400~1200 mm
(15.7-47.2")
Management
Ethernet
AR
Heat Dissipation (Excluding PoE Output)
341.2 BTU/hr
Weight
Without mounting brackets: 4.8 kg (10.6 lb)
With mounting brackets: 4.9 kg (10.8 lb)
Enclosure Material
SGCC steel
LCM Display
1.3" Touchscreen
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Etherlighting™


Ethernet
Yes


SFP+
Yes
LEDs


System
Status
Ambient Operating Humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
