Description
This active optical DisplayPort 1.4 cable lets you connect your DP laptop or desktop computer to an ultra-high definition 8K monitor, TV or projector. The built-in active signal booster ensures a reliable connection at a distance up to 15 m (49.2 ft.) between your DisplayPort enabled devices.
This durable yet lightweight active DP 1.4 cable features both copper and optical fiber conductors enabling a more flexible installation with minimal clutter. Plus, the cable features built-in amplifier circuitry which actively boosts the DisplayPort signal with no external power needed. The DisplayPort connectors also feature latches that provide a secure connection between your devices.
Comprised of a fiber and copper wire mix, this active cable is less susceptible to EMI interference, for a clear and reliable audio/video signal.
Note: This cable features unidirectional architecture, please refer to the ""display"" label on the HDMI connectors to ensure installed in the correct direction.
Key features
- Resolutions up to 8K at 60Hz
- HDCP 2.2 support
- High Bit Rate 3 (HBR3) bandwidth of 32.4Gbps
- High Dynamic Range (HDR)
- Multi-Stream Transport (MST) for daisy-chaining multiple monitors
- 32 uncompressed digital audio channels
- Backward compatible with 5K 60Hz, 4K 120Hz and previous generations of DP
- DISPLAYPORT 1.4 OPTICAL CABLE: 49.2'/15m hybrid copper & fiber DisplayPort 1.4 cable; 8K 60Hz (7680x4320), 4K 120Hz (3840x2160), 32.4Gbps, HDR10, HBR3, 32ch audio (5.1/7.1/Dolby TrueHD/Atmos), MST, GTC for precise audio channel timing; future-proof for 8K
- ACTIVE CIRCUITRY: DisplayPort Active Optical cable with unique DisplayPort bus powered Electro-Optical amplifier boosts video signals over longer distances up to 15 meters (49.2 feet) (no external power supply needed); Latching DP connectors
- RELIABLE DESIGN: DP Active Optical Cable (AOC) w/ flexible PVC jacket and strain relief absorb stress of frequent bends; Internal wire manager, metal connector sub-structure & Al-Mylar Foil with Braid provide EMI shielding & superior signal integrity
- APPLICATIONS: Ideal for home, office, boardroom, classroom; works w/ professional workstations: Dell XPS 11th Gen, HP Z2 G8 Tower with Radeon Vega Frontier/Pro WX Series/W5500/Pro Duo & NVIDIA Quadro P graphics cards; Use with Ultra HD (UHD) monitors/TV
- DisplayPort version 1.4 cable
- DP Male/Male Cord
- PVC Jacket
- Al-Mylar foil w/ Braid
- DSC 1.2, HDCP 2.2
- Works w/ DP 1.3/1.2 (1080p/4K)
- 2-Year Warranty
- Features : Active,Signal Booster,HDCP 2.2,Flexible,Locking Latch,EMI Protection,Latching Connector,Display Stream Compression (DSC) 1.2,Multi-Stream Transport (MST) Support,Strain Relief,Stress Resistant
- Dell XPS 11th Gen
- HP Z2 G8 Tower
- Radeon Vega Frontier/Pro WX Series/W5500/Pro Duo
- NVIDIA Quadro P Graphics Cards
- Experience What DisplayPort 1.4 Has to Offer
- This 8K DisplayPort cable supports all DP 1.4 features:
- Easy Installations
- DP14MM15MAO is backed by a StarTech.com lifetime warranty and free lifetime technical support
Specifications
- SPECS: 15 m (49.2 ft)
- Note: DP connector labelled "Display End" connects to display
- Data Transfer Rate: 32.4 Gbit/s
- Environmental Certification: RoHS,REACH,WEEE
- Cable Type: Fiber Optic
- Environmentally Friendly: Yes
- Shielding: Yes
- Device Supported: Notebook,Audio/Video Device,Desktop Computer,Monitor,TV,Projector,Digital Signage Display,Graphics Card
- Limited Warranty: Lifetime
- Packaged Quantity: 1
- Connector Plating: Nickel
- Supported Resolution: 7680 x 4320
- Product Type: Video Cable
- Manufacturer: StarTech.com
- Cable Length: 49.2 ft
- Compatibility: Dell XPS 11th Gen HP Z2 G8 Tower Radeon Vega Frontier/Pro WX Series/W5500/Pro Duo NVIDIA Quadro P Graphics Cards
- Country of Origin: Taiwan
- American Wire Gauge: 28 AWG
- Connector on First End Details: 1 x 20-pin DisplayPort 1.4 Digital Audio/Video - Male
- Jacket Material: Polyvinyl Chloride (PVC)
- Product Color: Black
- Connector on Second End Details: 1 x 20-pin DisplayPort 1.4 Digital Audio/Video - Male
- Connector Type on First End: DisplayPort 1.4 Digital Audio/Video - Male
- Connector Type on Second End: DisplayPort 1.4 Digital Audio/Video - Male
