Description
2.5G Ports for WiFi 7/6E/6
16� 2.5 Gbps Ports Unlock the Full Potential of WiFi 7/6E/6 APs
10G Lightning-Fast Uplink Connection
2� 10 Gbps SFP+ Slots for High-Bandwidth Connectivity
250W PoE Budget
8� PoE+ Ports with Total 250 W Power Budget*
Centralized Cloud Management
SDN Solutions Integration for a Highly Efficient Network
Unlock the Full Potential of WiFi 7/6E/6 with Multi-Gigabit PoE+ Ports
Featuring 8x PoE+ 2.5G ports, the switch is capable of future network expansion and deployment, providing sufficient bandwidth for incoming WiFi 7/6E/6 APs. Designed to use a single Ethernet cable for both data and power transmission, it supports up to 250W total PoE power budget* and flexible installation to fit in various application scenarios.
Enterprise Switch with 10G Uplink
2� 10 Gbps SFP+ slots provide non-blocking switching performance and ultra-low latency, so reliable and lightning-fast connections to server and other switches are easily built.
Software Defined Networking (SDN) with Cloud Access
Omada's Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network-all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.
Advanced L3 Features
An abundance of L2+ and L3 features are supported to help build a highly scalable and robust network, providing a reliable and efficient solution for enterprises, campuses and ISPs.
Secure Networking
Security features include IP-MAC-Port-VID Binding, Port Security, Storm Control and DHCP Snooping to defend against a range of network threats. An integrated list of common DoS attacks is available, making it easier than ever to prevent them. In addition, the Access Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets based on source and destination MAC address, IP address, TCP/UDP ports or VLAN ID. Users' network access can be controlled via 802.1X authentication, which works with a RADIUS/Tacacs+ server to grant access only when valid user credentials are provided.
Enterprise Level Features
A complete lineup of L2+ features are supported, including 802.1Q VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol, and 802.3x Flow Control. Advanced IGMP Snooping ensures the switch intelligently forwards multicast streams to only the appropriate subscribers, cutting out unnecessary traffic, while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Static Routing is a simple way of segmenting the network and internally routs traffic through the switch for improved efficiency.
Advanced QoS
Voice and video traffic can be prioritized based on IP address, MAC address, TCP port number, UDP port number, and more. With QoS (Quality of Service), voice and video services remain smooth, even when bandwidth is in short supply.
ISP Features
QinQ, L2PT PPPoE ID Insertion and IGMP authentication features are provided, developed with service providers in mind. 802.3ah OAM and Device Link Detection Protocol (DLDP) offer easy monitoring and troubleshooting of Ethernet links.
IPv6 Support
IPv6 functions such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, Path Maximum Transmission Unit (PMTU) Discovery and IPv6 Neighbor Discover guarantee your network is ready for the Next Ge
- Cascade to other network devices through the uplink port to expand your local area network
- Features 16 networking ports to easily establish a local network or expand your existing one
- PoE+ port to receive data and up to 25.5 W of power on a single cable in places where a power outlet is not available
- Supports layer 3 switching for enhanced performance and usability
- The unit is standalone and you can place it anywhere on a flat surface
- Management capability provides control over setup and configuration of your network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Ethernet Technology : 2.5 Gigabit Ethernet,10 Gigabit Ethernet
- Power Source : Power Supply,AC,PoE+
- Layer Supported : 3
- PoE Budget : 240 W
- Input Voltage : 120 V AC,230 V AC
- Port/Expansion Slot Details : 8 x 2.5 Gigabit Ethernet Network,2 x 10 Gigabit Ethernet Expansion Slot,8 x 2.5 Gigabit Ethernet PoE+
- PoE (RJ-45) Port : Yes
- Form Factor : Rack-mountable,Standalone
- Manufacturer Website Address : http://www.tp-link.com
- Network (RJ-45) : Yes
- Uplink Port : Yes
- Product Type : Ethernet Switch
- Stack Port : Yes
- Number of Total Expansion Slots : 2
- Networking Standards : IEEE 802.3ad,IEEE 802.3x,IEEE 802.1D,IEEE 802.1s,IEEE 802.1w,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1x,IEEE 802.3at,IEEE802.3af
- Manufacturer : TP-LINK Technologies Co., Ltd
- Total Number of Network Ports : 16
- Power Consumption : 299.40 W
- Manageable : Yes
- Media Type Supported : Twisted Pair,Optical Fiber
- Network Technology : 2.5GBase-T,10GBase-X
- Product Line : Omada
- Expansion Slot Type : SFP+
- Number of SFP+ Slots : 2
