Description
Features | 5-Port Unmanaged Ethernet Switch Connects Your Devices to a LAN
This space-saving switch with EIP QoS transmits data over an Ethernet network. Five auto-negotiating 10/100 Mbps ports send data only to the devices designated to receive it, which improves the efficiency and potential throughput of the network.
Ruggedized Metal Housing Built to Last in Harsh Environments
The compact NFI-U05A adds 10/100 Mbps Ethernet capacity to your industrial and commercial applications, such as factory floors, warehouse operations and other environments with space constraints and wide temperature ranges. The industrial-grade high-strength case withstands vibration, shock and free fall. It can also operate in extreme temperatures ranging from -40 to 75 degrees Celsius (-40 to 167 degrees Fahrenheit).
Works with the Most Popular Web Browsers
? The NFI-U05A is browser-based and works independently from the connected computer's operating system. Because switch compatibility is based on common hardware standards, rather than system software dependencies, the NFI-U05A accommodates most platforms. Preferred web browsers include Google Chrome (on both Windows and macOS) and Microsoft Edge (Windows only).
- Quickly and easily set up a wired network with 5 networking ports
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- The unmanaged switch provides a quick, easy and cost-saving way to add wired networking to your home, office or small business; no intervention needed
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Environmental Certification : RoHS,REACH
- Ethernet Technology : Gigabit Ethernet
- TAA Compliant : Yes
- Environmentally Friendly : Yes
- Power Source : DC
- Layer Supported : 2
- Input Voltage : 12 V DC,48 V DC
- Port/Expansion Slot Details : 5 x Gigabit Ethernet Network
- Limited Warranty : 3 Year
- Product Material : Aluminum,Metal
- Form Factor : DIN Rail Mountable,Wall Mountable,Compact
- Package Contents :
- NFI-U05A Ethernet Switch
- DIN rail-mounting Clip (pre-installed)
- Wall-mounting Bracket (pre-installed)
- Owner's Manual
- Manufacturer Website Address : https://tripplite.eaton.com/
- Network (RJ-45) : Yes
- Plug/Connector Type : Terminal Block (3 Wire)
- Product Type : Ethernet Switch
- Networking Standards : IEEE 802.1p,IEEE 802.3,IEEE 802.3u,IEEE 802.3x
- Manufacturer : Tripp Lite by Eaton
- Product Model : NFI-U05A
- Total Number of Network Ports : 5
- Power Consumption : 3 W
- Manageable : No
- Media Type Supported : Twisted Pair
- Network Technology : 10/100/1000Base-T
