Description
Protect Your Electronics with Voltage Regulation, Surge Suppression and Battery Backup
Line-interactive UPS offers voltage regulation, surge suppression and battery backup support. It regulates brownouts as low as 170V and overvoltages as high as 280V back to usable levels without using battery power. Both CEE 7/7 Schuko UPS outlets offer battery backup, automatic voltage regulation and AC surge suppression. Three front panel LEDs and audible alarm combine to indicate off/on power status, line power availability, battery mode operation, low battery, overload, battery replacement and fault mode.
Operate Your Connected Equipment During Short-Term Outages
This UPS supports an entry-level PC consuming 60W continuous up to 32 minutes during power failure condition and a 50% load of 120W for 7 minutes. It also enables users to operate connected equipment during short-duration outages without interruption and shut down without data loss during longer outages. All the UPS Schuko outlets receive battery backup.
Two-Year Limited Warranty
This UPS is backed by a two-year limited warranty, ensuring reliability and performance.
- Correct brownouts as low as 170V and overvoltages as high as 280V without using battery
- 650VA capacity supports a variety of desktop and networking devices
- Ultra-compact design saves space
- 2-year limited warranty
- Receptacle Detail : 2 x CEE 7/7 (SCHUKO)
- Phase : Single Phase
- Form Factor : Tower
- Package Contents :
- OMNIVSX650D 650VA Tower UPS
- Owner's manual
- Backup/Run Time (Full Load) : 1 Minute
- Load Capacity : 650 VA/360 W
- Battery Chemistry : Lead Acid
- Manufacturer : Tripp Lite by Eaton
- Product Model : OMNIVSX650D
- Backup/Run Time (Half Load) : 6 Minute
- Receptacle Type : Schuko CEE 7/7
- Environmentally Friendly : Yes
- Input Voltage : 230 V AC
- Transfer Time : 6 ms
- Limited Warranty : 2 Year
- Typical Battery Recharge Time : 8 Hour
- Waveform Type : Pulse-width Modulated Sine Wave
- Plug/Connector Type : Schuko CEE 7/7
- Product Type : Line-interactive UPS
- Application/Usage : Desktop Computer,Electronic Device,Telephone System,POS Terminal,Kiosk,ATM,Network Device
- Output Voltage : 220 V AC,230 V AC,240 V AC
- AVR : Yes
- Country of Origin : China
- DC System Voltage : 12 V DC
- Battery Size : 12V
- Maximum Operating Elevation : 6561.68 ft (2000000 mm)
- Thermal Dissipation : 26 BTU/h
- Maximum Operating Temperature : 104°F (40°C)
- Battery Characteristics : Valve-regulated
- Output Frequency : 60 Hz
- Storage Temperature : 5°F (-15°C) - 113°F (45°C)
- EMI/RFI Noise Filter : Yes
- Input Frequency : 50 Hz
- Surge Energy Rating : 312 J
- Alarm : Low Battery,Overload,Replace Battery,Fault
- Storage Relative Humidity : 90%
- Status Indicators :
3 front panel LEDs:
- Off/on power status
- Line power availability
- Battery mode operation
- Overload
- Replace-battery
- Fault-mode
- Manufacturer Website Address : https://tripplite.eaton.com/
