Description
Protects Mission-Critical Rack-Mounted Equipment
- Provides fully regulated sine wave AC output for servers, network storage devices and telecom hardware
- Audible alarm signals loss of utility power, overload, low battery and fault conditions
- 8 NEMA 5-15R outlets
- 10-ft. (3.05 m) power cord with 120V NEMA 5-15P input
- 0.9 power factor rating
- 570-joule surge suppression rating
Reliable Battery Backup
- Supports half load up to 13 min. and full load up to 4.5 min.
- Internal batteries designed for hot-swap field replacement
- 95% line-power efficiency rating saves money in energy costs
2 Load Banks with Switchable Outlets
- Can control 4 outlets remotely to reboot equipment or shed nonessential loads
Automatic Voltage Regulation (AVR)
- Maintains 120V nominal output over input range of 83V-147V without using battery power
EMI/RFI Line Noise Filtering
- Removes electromagnetic and radio frequency interference that can disrupt or damage equipment's performance
Interactive LCD Screen
- Front-panel LCD signals operating mode, load level, voltage, battery charge and estimated runtimes
- Rotates for easy viewing in rack-mount or tower configurations
Network Management Cards
- Compatible with Tripp Lite UPS management card options TLNETCARD, WEBCARDLX, SNMPWEBCARD and RELAYIOCARD
Communications Ports
- USB & Serial ports enable data-saving unattended shutdown when used with Tripp Lite's PowerAlert software, available via FREE download from
- EPO">www.tripplite.com/poweralert port supports emergency shutdown in large facilities
- EPO">
Versatile Installation Options
- EPO">
- Hardware included for 4-post mounting in 2U of EIA-standard 19 in. rack
- Mounts on wall or 2-post rack with optional 2POSTRMKITWM accessory
- Mounts in upright tower position with optional 2-9USTAND accessory
- EPO">
- 13 min. runtime at half load; 4.5 min. at full load
- Interactive LCD monitoring screen
- Network power management and control capability
- Corrects under- and overvoltages from 83V to 147V
- 8 NEMA 5-15R outlets-4 switchable via network interface
- Environmental Certification : RoHS
- Receptacle Type : NEMA 5-15R
- Receptacle Detail : 8 x NEMA 5-15R
- Input Voltage : 110 V AC
- Typical Battery Recharge Time : 4 Hour
- Limited Warranty : 3 Year
- Packaged Quantity : 1 Each
- Backup/Run Time (Full Load) : 4.50 Minute
- Manufacturer Website Address : http://www.tripplite.com
- Package Contents :
- SmartPro 1500RM2U UPS
- Mounting hardware for 4 post rackmount installation
- Cabling for USB & DB9 monitoring and EPO switching
- PowerAlert unattended shutdown and UPS/Power monitoring software
- Warranty information
- Plug/Connector Type : NEMA 5-15P
- Product Type : Line-interactive UPS
- Load Capacity : 1.50 kVA/1.35 kW
- Manufacturer : Tripp Lite by Eaton
- Output Voltage : 120 V AC
- Country of Origin : China
- Rack Height : 2U
- Product Line : SmartPro
- Waveform Type : Sine Wave
- Battery Life : 6 Year
- Battery Chemistry : Lead Acid
- Hot Swappable : Yes
- Backup/Run Time (Half Load) : 13 Minute
- Form Factor : Rack-mountable
- Environmentally Friendly : Yes
- Transfer Time : 4 ms
- Replaceable Battery : Yes
- DC System Voltage : 36 V DC
- Network Management : SNMP/Webcard
- Sound Emission (A-Weighted) : 45 dB(A)
- Maximum Operating Elevation : 6561.68 ft (2000000 mm)
- Thermal Dissipation : 267 BTU/h
- Maximum Operating Temperature : 104°F (40°C)
- Battery Characteristics : Valve-regulated
- Storage Temperature : 5°F (-15°C) - 122°F (50°C)
- USB : Yes
- Overload Protection : Yes
- Surge Energy Rating : 570 J
- Alarm : On Battery,Overload,Low Battery
- Storage Relative Humidity : 0% - 95%
- Status Indicators : LED Indicator
