Onduleur Tripp Lite SmartPro SMART2200RM2U 2200 VA montable en rack SMART2200RM2U

Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for critical server, network and telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS) with built-in Auto-Voltage Regulation (AVR) actively corrects brownouts and overvoltages back to usable levels while maintaining a full battery charge in case of power failure. Tripp Lite's unique configuration excels in exceptionally poor-power environments with two separate levels of voltage boost to correct both slight undervoltages and severe brownout conditions. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Super-fast switchover from line to battery power occurs within milliseconds to maintain operation of connected equipment without interruption or reboot. 96% line-mode efficiency offers reduced heat emissions and operating costs. Network management interfaces support communications via USB, RS-232 and slot for network management accessory card. HID-compliant USB port enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment load levels, self-test data and utility power conditions. PowerAlert UPS monitoring software is available via free download. Switched output load banks enable scheduled and real-time remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display panel easily rotates for viewing in rackmount or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode configuration options. Programmable self-test. Field-replaceable, hot-swappable battery modules.

Key features

• 120V NEMA 5-20P input, 4 NEMA 5-15R & 4 NEMA 5-15/20R outlets
• USB, RS232, EPO and slot for Network Card options
• 96% line-mode efficiency, 2 switched load banks
• 0.9 Power Factor, Interactive LCD interface
• 120V output, Corrects brownouts and overvoltages from 83V to 145V
• 2.2kVA / 2200VA / 1920W line interactive 2U rack/tower UPS, Sine Wave
• In the box: SMART2200RM2U UPS System, PowerAlert Software CD, USB Cable, Serial Cable, EPO Cable, Owner's Manual with Warranty Information
• Status Indicators : 5 Front Panel Leds: Green Power Led Green Voltage Correction Led 3 Color Battery Charge Led 3 Color Output Load Led Red Battery Warning Led
• Green Power Led
• Green Voltage Correction Led
• 3 Color Battery Charge Led
• 3 Color Output Load Led
• Red Battery Warning Led

Specifications

• Receptacle Type: NEMA 5-15R,NEMA 5-15/20R
• Receptacle Detail: 4 x NEMA 5-15R,4 x NEMA 5-15/20R
• Environmental Certification: RoHS
• Input Voltage: 110 V AC
• Form Factor: Rack-mountable
• Backup/Run Time (Full Load): 5 Minute
• Load Capacity: 2.20 kVA/1.92 kW
• Output Voltage: 120 V AC,110 V AC
• Backup/Run Time (Half Load): 13 Minute
• Waveform Type: Sine Wave
• Environmentally Friendly: Yes
• Typical Battery Recharge Time: 4.50 Hour
• Limited Warranty: 3 Year
• Packaged Quantity: 1 Each
• Plug/Connector Type: NEMA 5-20P
• Product Type: Line-interactive UPS
• Manufacturer: Tripp Lite by Eaton
• Product Model: SMART2200RM2U
• Country of Origin: China
• Rack Height: 2U
• Product Line: SmartPro
• TAA Compliant: Yes
• Hot Swappable: Yes
• Software Included: PowerAlert Software
• Network Management: SNMP Manageable
• Serial Port: Yes
• Maximum Operating Temperature: 104°F (40°C)
• USB: Yes
• Alarm: On Battery,Overload,Low Battery
