Description
Switched Rack Power Distribution Units (PDUs) provide advanced load monitoring combined with remote on/off switching control of individual outlets for power cycling, delayed power sequencing, and outlet use management.
Explore APC Rack Power Distribution in 3D animation.
APC Switched Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and active monitoring. Remote outlet level controls allow power on/off functionality for power cycling to remotely reboot equipment and restrict unauthorized use of individual outlets. Power sequencing time delays allow users to define the order in which to power up or down attached equipment to avoid circuit overload. Current metering provides real-time remote monitoring of connected loads with user-defined alarms to warn of potential circuit overloads. Users can access, configure, and control Switched Rack PDUs through secure Web, SNMP, Command Line Interface, or Telnet Interfaces which are complimented by APC Centralized Management platforms using StruxureWare Data Center Expert, Operations, Capacity, and Energy Efficiency. New AP8000 series Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, and locking IEC receptacles.
Explore APC Rack Power Distribution in 3D animation.
APC Switched Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and active monitoring. Remote outlet level controls allow power on/off functionality for power cycling to remotely reboot equipment and restrict unauthorized use of individual outlets. Power sequencing time delays allow users to define the order in which to power up or down attached equipment to avoid circuit overload. Current metering provides real-time remote monitoring of connected loads with user-defined alarms to warn of potential circuit overloads. Users can access, configure, and control Switched Rack PDUs through secure Web, SNMP, Command Line Interface, or Telnet Interfaces which are complimented by APC Centralized Management platforms using StruxureWare Data Center Expert, Operations, Capacity, and Energy Efficiency. New AP8000 series Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, and locking IEC receptacles.
- Provide circuit protection and easy configuration for trouble-free access
- Remotely control individual outlets for rebooting of locked equipment with switched PDUs
- Rack Height : 0U
- Phase : Three Phase
- Input Current : 50 A
- Protection Type : Overload Protection
- Mount Type : Rack-mountable
- PDU Type : Switched
- Output Voltage : 208 V AC
- Manufacturer Website Address : http://www.schneider-electric.com
- Environmentally Friendly : Yes
- Plug/Connector Type : CS8365
- Environmental Certification : RoHS
- Manufacturer : Schneider Electric SA
- Product Type : PDU
- Limited Warranty : 2 Year
- Power Rating (Watt) : 12.50 kW
- Receptacle Type : IEC 60320 C19,IEC 60320 C13
- Receptacle Detail : 3 x IEC 60320 C19,21 x IEC 60320 C13
- Package Contents :
- Rack PDU, Switched, Zero U,12.5kW,208V,(21)C13&(3)C19; 10' Cord
- Cord retention bracket(s)
- Documentation CD
- Installation guide
- Rack mounting brackets
- RS-232 configuration cable
- Toolless mounting kit
- Input Voltage : 230 V AC
