Description
Smart-UPS™ are trusted by millions of IT professionals throughout the world to protect equipment and critical data from costly interruptions by supplying reliable, network-grade power reliably and efficiently. Available in a variety of forms factors and classes (entry level, standard and extended run), there is a model for nearly every application and budget. Standard models are the most popular UPS in the world for business servers, storage and network devices and have long been considered the benchmark for reliability and manageability. Entry level Smart-UPS models are an economical choice for small and medium businesses looking to protect small networking devices, point-of-sale (POS) equipment and entry level servers. The extended run models accept external battery packs for long runtime to power critical servers, security and communication systems through outages that could last hours.
Adaptability | Adjustable voltage sensitivity - Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Adjustable voltage-transfer points - Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Availability | Power conditioning - Protects connected loads from surges, spikes, lightning, and other power disturbances.
Intelligent battery management - Maximizes battery performance, life, and reliability through intelligent, precision charging.
Boost and Trim Automatic Voltage Regulation (AVR) - Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
Disconnected battery notification - Warns when a battery is not available to provide backup power.
Automatic self-test - Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Automatic restart of loads after UPS shutdown - Automatically starts up the connected equipment upon the return of utility power.
Temperature-compensated battery charging - Prolongs battery life by regulating the charge voltage according to battery temperature.
Manageability | Serial connectivity - Provides management of the UPS via a serial port.
LED status indicators - Quickly understand unit and power status with visual indicators.
Audible alarms - Provides notification of changing utility power and UPS conditions.
Network manageable - Provides remote power management of the UPS over the network.
USB connectivity - Provides management of the UPS via a USB port (not available on all models).
Safety | Safety-agency approved - Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
- Experience higher efficiency with lower energy cost
- Keep your sensitive devices powered with a backup of up to 7 minute at full load
- Receptacle Detail : 6 x NEMA 5-15R
- TAA Compliant : Yes
- Transfer Time : 10 ms
- Typical Battery Recharge Time : 3 Hour
- Waveform Type : Sine Wave
- Form Factor : Rack-mountable
- Manufacturer Website Address : http://www.schneider-electric.com
- Backup/Run Time (Full Load) : 7 Minute
- Battery Life : 5 Year
- Product Type : Line-interactive UPS
- Load Capacity : 1.44 kVA/1 kW
- Battery Chemistry : Lead Acid
- Manufacturer : Schneider Electric SA
- Input Voltage Range : 82 V AC - 144 V AC
- Output Voltage : 120 V AC
- Backup/Run Time (Half Load) : 26 Minute
- AVR : Yes
- Product Line : Smart-UPS
- Serial Port : Yes
- Sound Emission (A-Weighted) : 45 dB(A)
- Thermal Dissipation : 255 BTU/h
- Maximum Operating Temperature : 104°F (40°C)
- Output Frequency : 60 Hz
- Storage Temperature : -4°F (-20°C) - 131°F (55°C)
- Battery Energy : 1555.2 kJ
- Input Frequency : 60 Hz
- Alarm : Changing Utility Power
- Storage Relative Humidity : 0% - 95%
- USB (HID Compliant) Port : Yes
- Status Indicators :
LED Display:
- Load bar-graphs
- Battery bar-graphs
- On line
- On battery
- Replace battery
- Overload indicators
- Environmentally Friendly : Yes
- Environmental Certification : RoHS
- Number of Battery & Surge Outlets : 6
- Input Voltage : 120 V
- Plug/Connector Type : NEMA 5-15P
- Additional Warranty Information : 3 years repair or replace (excluding battery) and 2 years for battery
- Surge Energy Rating : 693 J
- Receptacle Type : NEMA 5-15P
