Description
Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Smart-UPS™ are trusted by millions of IT professionals throughout the world to protect equipment and critical data from costly interruptions by supplying reliable, network-grade power reliably and efficiently. Available in a variety of forms factors and classes (entry level, standard and extended run), there is a model for nearly every application and budget. Standard models are the most popular UPS in the world for business servers, storage and network devices and have long been considered the benchmark for reliability and manageability. Entry level Smart-UPS models are an economical choice for small and medium businesses looking to protect small networking devices, point-of-sale (POS) equipment and entry level servers. The extended run models accept external battery packs for long runtime to power critical servers, security and communication systems through outages that could last hours.
- Works adequately in situations where the supply is prone to sags and surges
- Up to 2.70 minute runtime on full load to preserve critical data from power shortage interruptions
- Energy Star : Yes
- Rack Height : 1U
- Product Line : Smart-UPS
- Form Factor : Rack-mountable
- Manufacturer : Schneider Electric SA
- Product Type : Line-interactive UPS
- Limited Warranty : 5 Year
- Country of Origin : Philippines
- Transfer Time : 6 ms
- Input Voltage : 120 V AC
- AVR : Yes
- Output Voltage : 120 V AC
- Manufacturer Website Address : http://www.schneider-electric.com
- Typical Battery Recharge Time : 3 Hour
- Backup/Run Time (Full Load) : 2.70 Minute
- Plug/Connector Type : NEMA 5-15P
- Load Capacity : 500 VA/400 W
- Receptacle Type : NEMA 5-15R
- Receptacle Detail : 4 x NEMA 5-15R
- Package Contents :
- Smart-UPS 500VA Rack-mountable UPS
- CD with software
- Documentation CD
- Installation guide
- Rack mounting support rails
- USB cable
- Environmentally Friendly : Yes
- Battery Chemistry : Lithium Ion (Li-Ion)
- Backup/Run Time (Half Load) : 6.30 Minute
- Waveform Type : Sine Wave
- Replaceable Battery : Yes
- Application/Usage : Server,POS Terminal,Router,Switch,Network Hub,IT Equipment,Network Device,Business,Storage System,Critical System,Security System,Communication System
- Hot Swappable : Yes
- Software Included : Powerchute Business Edition
- Serial Port : Yes
- Sound Emission (A-Weighted) : 45 dB(A)
- Maximum Operating Elevation : 6561 ft (1999792.80 mm)
- Maximum Operating Temperature : 104°F (40°C)
- Output Frequency : 60 Hz
- Storage Temperature : 5°F (-15°C) - 113°F (45°C)
- Battery Energy : 108 kJ
- Input Frequency : 63 Hz
- Overload Protection : Yes
- Surge Energy Rating : 680 J
- Alarm : On Battery,Low Battery,Configurable Delay
- Maximum Storage Elevation : 49212 ft (14999817.60 mm)
- USB (HID Compliant) Port : Yes
- Status Indicators :
LED Status Display:
- On Battery
- On Line
- Number of Battery & Surge Outlets : 4
- Environmental Certification : RoHS
- Product Color : Silver
- Additional Warranty Information : 5 year repair or replace
- Cord Length : 6 ft
