Description
Intel Xeon Quad-Core CPU
The Lockerstor 10 Pro features a powerful Intel 9th generation Xeon with four cores. Not only is the Xeon extremely fast in both read and write speeds, but also lends incredible performance to virtual machines and Docker apps.
Powerful Hardware and Top flight performance
Intel Xeon 9th generation Quad-Core CPU.
Supports DDR4-2666 ECC RAM.
Dual M.2 NVMe SSD ports for fast caching.
Brings the smoothest work experience with 10-Gigabit Ethernet, triple 2.5-Gigabit ports and USB 3.2 Gen2 ports.
Supports Wake on LAN on 2.5-Gigabit Ethernet ports
360° Backup solution and enterprise virtualization application
- MyArchive cold storage backups
- Snapshot Center, Cloud Backup Center, DataSync Center
- Complete iSCSI/IP-SAN and NFS support
- VMware, Citrix and Hyper-V ready
- Supports virtualization and Docker apps
10-Gigabit and Triple 2.5-Gigabit ports. Extreme speeds.
The all new Lockerstor 10 Pro NAS features a powerful Aquantia 10-Gigabit Ethernet port as well as triple Aquantia 2.5-Gigabit Ethernet ports. With a managed switch that supports multiple speeds, take advantage of up to 10 Gbps of speed on the 10-Gigabit port or up to 7.5 Gbps on all 2.5-Gigabit ports.
Server-grade ECC memory
ECC memory is memory usually used in servers for detection and correction of the most common kinds of data corruption. This can help prevent data loss due to electromagnetic interference or crashes, making the Lockerstor 10 Pro our most stable NAS ever.
Ten Bays with Two M.2 SSD Slots for Flexible Cached Storage
The Lockerstor 10 Pro is a cost-effective high capacity NAS designed for enterprise environments. The Lockerstor 10 Pro is flexible, supporting online capacity expansion and replacement. Online capacity expansion enables you to replace hard drives inside the NAS without downtime. If your budget and/or storage requirements are small, the Lockerstor 10 Pro enables your NAS to grow alongside your needs by first purchasing smaller drives and then add more drives as you need. Additional drives can be purchased as your storage requirements grow and all drives can be fully replaced while continuing to use your NAS. Combining this with ASUSTOR's MyArchive cold storage technology enables you to store a virtually unlimited amount of information.
SSD Cache
SSD caching on the Lockerstor 10 Pro brings SSD-like speeds to regular hard drives. Turbocharge your NAS by adding one or two SSDs to the M.2 slots inside your Lockerstor 10 Pro. Read and write files at speeds of over 1100 MB/s and watch as even big files are transferred over in seconds.
- Experience unmatched performance, built-in security and remote management capabilities with Intel Xeon 3.40 ghz processor
- RAID technology - data reliability, fault tolerance and improved overall performance
- Optimize business network's performance with 10 Gigabit Ethernet connectivity
- Protocols : IMAP,IPSec,TCP/IP,SMTP,HTTPS,LDAP,L2TP,SFTP,UDP,SSH,CHAP,FTPS,AFP,RTSP,FTP,SMB 2.0,IPv4,PAP,WEBDAV,SSL,iSCSI,SNMP,TLS,HTTP,TFTP,NFS,UPnP,RSync,POP3,DDNS,CIFS/SMB,IPv6,PPTP
- Flash Memory Capacity : 8 GB
- Maximum Power Supply Wattage : 350 W
- Controller Type : Serial ATA/600
- Total Number of USB Ports : 3
- Number of USB 3.2 Gen 1 Ports : 1
- Processor Type : Xeon
- Packaged Quantity : 1
- Processor Core : Quad-core (4 Core)
- RAID Supported : Yes
- Form Factor : Desktop
- Memory Technology : DDR4 SDRAM
- Package Contents :
- Lockerstor 10 Pro AS7110T SAN/NAS Storage System
- Quick Installation Guide
- 1 x AC Power Cord
- 3 x RJ-45 LAN Cable(Cat 5e)
- 1 x 10GBE LAN Cable(Cat 6a)
- 40 x Flat Head Screw (for 3.5" HDD)
- 40 x Flat Head Screw (for 2.5" HDD)
- 2 x M.2 Thumbscrews
- Manufacturer Website Address : http://www.asustor.com
- Processor Manufacturer : Intel
- Number of Power Supplies Installed : 1
- Manufacturer : ASUSTOR
- Product Model : AS7110T
- Processor Model : E-2224
- Number of Total Expansion Bays : 10
- Operating System : ADM 3.5
- RAID Levels : 0, 1, 5, 6, 10, JBOD
- Standard Memory : 8 GB
- Ethernet Technology : 10 Gigabit Ethernet,2.5 Gigabit Ethernet
- Number of Hard Drives Supported : 10
- Number of 2.5"/3.5" Bays : 10
- Number of USB 3.2 Gen 2 Ports : 2
- Number of Solid State Drive Supported : 10
- Limited Warranty : 5 Year
- Processor Speed : 3.40 GHz
- Network (RJ-45) : Yes
- Product Type : SAN/NAS Storage System
- HDMI : No
- Redundant Power Supply : No
- Number of Network (RJ-45) Ports : 4
- Product Line : Lockerstor 10 Pro
