Description
The CyberPower 16-outlet (6 Front and 10 Rear) rack mount basic power distribution unit (PDU15B6F10R) provides 120V 15A output. It distributes power to 16 NEMA 5-15R receptacles from a single NEMA 5-15P input, with unfiltered electrical pass-through. Designed for datacenters and other electrically demanding applications, this unit has a rugged, industrial-grade metal housing and a 15-foot AC power cord. It can be mounted either horizontally or vertically, includes a cord retention tray and is ETL/RoHS certified. A lifetime warranty ensures that this PDU is free of defects in design, assembly, material or workmanship.
- Basic PDU
- 16 NEMA 5-20R output receptacles (6 Front/10 Rear)
- 120V AC - 50/60Hz - 20-amp electrical capacity with circuit breaker
- 1U Rack Mount - Rugged industrial-grade metal housing
- 1U Rack Mount - Rugged industrial-grade metal housing
- 120V AC - 50/60Hz - 20-amp electrical capacity with circuit breaker
- Basic PDU
- 16 NEMA 5-20R output receptacles (6 Front/10 Rear)
- Energy Star : No
- Input Voltage : 120 V AC
- Rack Height : 1U
- Protection Type : Overload Protection
- PDU Type : Basic
- Mount Type : Rack-mountable
- Manufacturer Website Address : http://www.cyberpowersystems.com
- Output Voltage : 120 V AC
- Mounting Orientation : Vertical
- Environmentally Friendly : Yes
- Plug/Connector Type : NEMA 5-20P
- Environmental Certification : RoHS
- Manufacturer : CyberPower Systems, Inc
- Product Type : PDU
- Receptacle Type : NEMA 5-20R
- Limited Warranty : Lifetime
- Product Model : PDU20B6F10R
- Length : 2.25" (57.15 mm)
- Country of Origin : China
- Energy Star : No
- Rack Height : 1U
- Mounting Orientation : Vertical
- Environmentally Friendly : Yes
- Environmental Certification : RoHS
- Manufacturer : CyberPower Systems, Inc
- Product Type : PDU
- Limited Warranty : Lifetime
- Product Model : PDU20B6F10R
- Length : 2.25" (57.15 mm)
- Country of Origin : China
- Input Voltage : 120 V AC
- Protection Type : Overload Protection
- Mount Type : Rack-mountable
- PDU Type : Basic
- Output Voltage : 120 V AC
- Manufacturer Website Address : http://www.cyberpowersystems.com
- Plug/Connector Type : NEMA 5-20P
- Receptacle Type : NEMA 5-20R
