Description
The CyberPower Smart App Online OL6KRTHD high-density design offers more power in less space. In fact, it can be configured into 2U of rack space or as a tower, compared to 3U and 4U for similar competitive UPS models - giving you more room to grow. The OL6KRTHD features double-conversion topology for seamless power protection and a pre-installed RMCARD205.
For monitoring, this UPS offers a new state-of-the-art, multi-function, color matrix LCD screen that is simple to set up and easy to use. The color-coded alerts provide clear status of the UPS and the screen orientation rotates automatically when placed into a tower configuration.
The OL6KRTHD ensures maximum efficiency and capacity output with a Power Factor rating (PF) of 1. The energy-saving GreenPower UPS™ ECO Mode enables up to 96% efficiency while reducing power consumption and thermal dissipation. The variable 7-speed fan provides automatic thermal management, based on power load, to reduce noise.
The optional BP144VL2U01 Extended Battery Module (EBM) expands runtime and up to ten EBMs can be connected in a daisy-chain to the UPS for more backup power. Plus, it's all backed by a three-year warranty (including batteries) and a ,300,000 Connected Equipment Guarantee.
- Capacity: 6000 VA / 6000 W
- High Density: 2U Size
- Power Factor (PF): 1
- Topology: Double-conversion
- Waveform: Sine Wave
- Output: 200, 208, 220, 230, 240 VAC User Configurable ±2%
- Plug type & cord: Hardwire with NEMA L6-30P Power Cord Option
- Outlet types: 2 � NEMA L6-20R, 2 x NEMA L6-30R
- Communication ports: USB, Serial, SNMP, EPO
- Management software: PowerPanel® Business Edition
- Input Voltage : 230 V AC
- Manufacturer Website Address : http://www.cyberpowersystems.com
- Output Voltage : 240 V AC
- Product Condition : New
- Input Voltage Range : 200 V AC - 240 V AC
- Waveform Type : Sine Wave
- Backup/Run Time (Half Load) : 4.90 Minute
- Network Management : SNMP/HTTP Remote Monitoring
- Country of Origin : Taiwan
- Replaceable Battery : Yes
- Energy Star : Yes
- Product Series : Smart App Online UPS
- Rack Height : 2U
- Package Contents :
- Smart App Online OL6KRTHD 6KVA Tower/Rack Convertible UPS
- Mounting Hardware
- Battery Chemistry : Lead Acid
- Environmentally Friendly : Yes
- Typical Battery Recharge Time : 4 Hour
- Backup/Run Time (Full Load) : 1.40 Minute
- Plug/Connector Type : Hardwired
- Environmental Certification : RoHS
- Form Factor : Rack/Tower
- Load Capacity : 6 kVA
- Manufacturer : CyberPower Systems, Inc
- Product Type : Dual Conversion Online UPS
- Receptacle Type : NEMA L6-30R
- Limited Warranty : 3 Year
- Receptacle Detail : 2 x NEMA L6-30R
- Product Model : OL6KRTHD
- Energy Star : Yes
- Rack Height : 2U
- Product Condition : New
- Environmentally Friendly : Yes
- Environmental Certification : RoHS
- Manufacturer : CyberPower Systems, Inc
- Product Type : Dual Conversion Online UPS
- Limited Warranty : 3 Year
- Product Model : OL6KRTHD
- Country of Origin : Taiwan
- Input Voltage : 230 V AC
- Output Voltage : 240 V AC
- Manufacturer Website Address : http://www.cyberpowersystems.com
- Input Voltage Range : 200 V AC - 240 V AC
- Waveform Type : Sine Wave
- Backup/Run Time (Half Load) : 4.90 Minute
- Network Management : SNMP/HTTP Remote Monitoring
- Replaceable Battery : Yes
- Product Series : Smart App Online UPS
- Package Contents :
- Smart App Online OL6KRTHD 6KVA Tower/Rack Convertible UPS
- Mounting Hardware
- Battery Chemistry : Lead Acid
- Typical Battery Recharge Time : 4 Hour
- Backup/Run Time (Full Load) : 1.40 Minute
- Plug/Connector Type : Hardwired
- Load Capacity : 6 kVA
- Form Factor : Rack/Tower
- Receptacle Type : NEMA L6-30R
- Receptacle Detail : 2 x NEMA L6-30R
