Description
The CyberPower Smart App Online OL6KSTF rack/tower step-down isolation transformer converts 200 V to 240 V input voltage originating from utility power, a UPS, or a generator to 120 V output.
The OL6KSTF has a capacity of 6,000 VA / 6,000 Watts. It features six (6) NEMA 5-20R receptacles that can support output to NEMA 5-15P and 5-20P plug power cords. A hardwire output terminal block provides a means to connect to an electrical subpanel.
The included 6-foot cord (NEMA L6-30P plug to ROJ) connects the OL6KSTF to input power. Over temperature protection safeguards your OL6KSTF from damage if the internal heat exceeds safe operating parameters.
A Three-Year Warranty ensures that this extended battery module has passed our highest quality standards in design, assembly, material or workmanship.- Step-down transformer: 6,000 VA / 6,000 W
- Output: 120 V, 208 V, 50/60 Hz
- Power conversion: 208 V from utility, UPS, or generator to 120 V output
- Plug type & cord: 6 ft NEMA L6-30P power cord
- Outlets: (6) NEMA 5-20R, (1) Hardwire Terminal Block
- Form factor: 2U Rack/Tower convertible
- Overload protection: Output circuit breakers
- Over temperature protection: Yes
- Warranty: Three year
- Energy Star : No
- Product Series : UPS Hardware
- Input Voltage : 230 V AC
- Rack Height : 2U
- Package Contents :
- OL6KSTF Isolation/Step-Down Transformer
- 6ft NEMA L6-30 Locking Male Plug to 3-wire ROJ (Remove Outer Jacket) Power Cable (L630PHW6FT)
- 2 x Terminal Block Cable glands
- Left & Right Rackmount Rails
- Left & Right Hanging Brackets
- Input/Output Terminal Block Cover
- Quick Start Guide
- Registration Card
- 2U Rack Mount Ears (Tower Stands)
- Tower Installation Tie Plate
- 8 x M5X7L Black Flat Head Screws
- 12 x M5X12L Black Pan an Head Screws
- 6 x M5X6L silver pan head Screws
- 8 x Plastic Washers
- 12 x Screw Hole Dust Covers
- 12 x Rubber Pads
- Safety Instruction Card
- Manufacturer Website Address : http://www.cyberpowersystems.com
- Output Voltage : 208 V AC
- Environmentally Friendly : Yes
- Environmental Certification : RoHS
- Form Factor : Tower/Rack Mountable
- Power Rating : 6 kVA
- Manufacturer : CyberPower Systems, Inc
- Input Receptacle Type : Hardwired
- Product Type : Isolation/Step-Down Transformer
- Maximum Line Current : 30 A
- Limited Warranty : 3 Year
- Output Receptacle Type : Terminal Block
- Product Model : OL6KSTF
- Country of Origin : China
- Energy Star : No
- Rack Height : 2U
- Environmentally Friendly : Yes
- Environmental Certification : RoHS
- Form Factor : Tower/Rack Mountable
- Manufacturer : CyberPower Systems, Inc
- Product Type : Isolation/Step-Down Transformer
- Limited Warranty : 3 Year
- Product Model : OL6KSTF
- Country of Origin : China
- Product Series : UPS Hardware
- Input Voltage : 230 V AC
- Package Contents :
- OL6KSTF Isolation/Step-Down Transformer
- 6ft NEMA L6-30 Locking Male Plug to 3-wire ROJ (Remove Outer Jacket) Power Cable (L630PHW6FT)
- 2 x Terminal Block Cable glands
- Left & Right Rackmount Rails
- Left & Right Hanging Brackets
- Input/Output Terminal Block Cover
- Quick Start Guide
- Registration Card
- 2U Rack Mount Ears (Tower Stands)
- Tower Installation Tie Plate
- 8 x M5X7L Black Flat Head Screws
- 12 x M5X12L Black Pan an Head Screws
- 6 x M5X6L silver pan head Screws
- 8 x Plastic Washers
- 12 x Screw Hole Dust Covers
- 12 x Rubber Pads
- Safety Instruction Card
- Output Voltage : 208 V AC
- Manufacturer Website Address : http://www.cyberpowersystems.com
- Power Rating : 6 kVA
- Input Receptacle Type : Hardwired
- Maximum Line Current : 30 A
- Output Receptacle Type : Terminal Block
