Description
The Eaton 9PX is a proven, best-in-class online double-conversion rackmount/tower UPS. The 9PX UPS features ABM technology, which extends battery service life up to 50 percent, and offers flexibility in battery types with nine models offering lithium-ion batteries. Select 9PX UPS models are bundled with theEaton Gigabit Network card, the first in the industry to comply with both UL and IEC cybersecurity standards. To complete your backup power solution, pair your 9PX with the Brightlayer Data Centers suitefor seamless management of your connected equipment.
Applications: IT, edge networks, medical/healthcare, universities, K-12, industrial automation, harsh electrical environments.
. .- Receptacle Detail : 6 x NEMA 5-20R,1 x NEMA L6-30R,1 x NEMA L14-30R
- Network Management : SNMP/Web,Network-M2 Card
- Serial Port : Yes
- Product Series : 9PX
- Form Factor : Rack/Tower
- Package Contents :
- 9PX3K3UNP1 3000VA Rack/Tower UPS
- 9PXPPDM1 PowerPass Distribution Module
- Gigabit Network Card (Network-M2)
- 4-Post Rail Kit
- User Manual
- Quick Start Guide
- Tower Pedestals
- Intelligent Power Software Suite CD
- RS-232 Serial Cable
- USB Cable
- Cable Gland for Hardwire Connection
- Phillips Head Screw Driver
- Manufacturer Website Address : http://www.eaton.com/EatonCom/Markets/NorthAmerica
- Number of USB Ports : 1
- Backup/Run Time (Full Load) : 7 Minute
- Load Capacity : 3 kVA/3 kW
- Energy Star : Yes
- Battery Chemistry : Lead Acid
- Manufacturer : Eaton Corporation
- Product Model : 9PX3K3UNP1
- Backup/Run Time (Half Load) : 19 Minute
- Rack Height : 6U
- Battery Characteristics : Sealed
- Output Frequency : 50 Hz,60 Hz
- Receptacle Type : NEMA 5-20R,NEMA L6-30R,NEMA L14-30R
- Output Power Factor : 1
- USB : Yes
- Input Voltage : 230 V AC
- Limited Warranty : 3 Year
- Waveform Type : True Sine Wave
- Input Frequency : 60 Hz,50 Hz,70 Hz,40 Hz
- Network (RJ-45) : Yes
- Plug/Connector Type : NEMA L6-30P
- Cord Length : 6 ft
- Product Type : Double Conversion Online UPS
- Replaceable Battery : Yes
- Application/Usage : Data Center,Equipment,IT,Edge Computing,Network,Medical,Healthcare,University,Industrial Automation System
- Hot Swappable : Yes
- Output Voltage : 120 V AC,208 V AC,240 V AC,100 V AC,200 V AC,115 V AC,230 V AC,127 V AC,220 V AC
