Description
Eaton Metered Input rack PDUs give you remote monitoring capabilities and provide access to your power data whenever you want it, wherever you are. You also can monitor your critical equipment within each color-coded outlet section from a single interface, achieve±1% billing grade accuracy and daisy chain four PDUs to share the same network connection and IP address.
- Allows phase branch level metering for load balancing
- IEC outlet eGrip plug retention: retains all standard IEC plugs
- Highly secure with user access control, password protection and SSL configurable to 1024 or 2048 bit
- Colour-coded outlet and branch circuits for simple load balancing
- Eaton Hydraulic Magnetic Circuit Breakers with accidental trip protection
- Receptacle Type : NEMA 5-20R
- Receptacle Detail : 12 x NEMA 5-20R
- Power Rating (Watt) : 1.92 kW
- Input Voltage : 120 V AC
- Product Series : Metered
- Limited Warranty : 3 Year
- Plug/Connector Detail : 1 x NEMA L5-20P
- Package Contents :
- ePDU Metered EMIT01-10 12-Outlet PDU
- SPK021-Installation
- SPK013-Network
- Manufacturer Website Address : http://www.eaton.com/EatonCom/Markets/NorthAmerica
- Network (RJ-45) : Yes
- Plug/Connector Type : NEMA L5-20P
- Product Type : PDU
- Manufacturer : Eaton Corporation
- Product Model : EMIT01-10
- Output Voltage : 120 V AC
- Mounting Orientation : Horizontal
- Input Current : 16 A
- Rack Height : 1U
- Country of Origin : China
- Product Line : ePDU
