Description
The EnGenius cloud-managed ECS1528T 24-port 13" 1U rackmount compact gigabit layer 2+ switch with 4 SFP+ uplink ports and multiple management options for large businesses to easily configure, monitor, and manage. Select Cloud or on-premises management options based on network architecture, administrative permissions, technical aptitude, or even budget.
- 24 10/100/1000 Base-T GbE Ports
- Full-Featured Layer 2+ Switching
- 13" 1U rackmount compact design
- 128 Gbps Switching capacity
- 4 10-Gigabit Dual-Speed SFP+ (fiber) uplink ports
- Real-Time System Metrics, Deep-Dive Analytics and Remote Configurations
- Quick-Scan Device Register, Remote Monitoring and Troubleshooting
- Advanced View Displays Network Topology with Devices and Relationships
- Hybrid Switch Supports Multiple Management Options
- Security - Access Control List/Port Security; 802.1X & RADIUS Authentication
- IGMP & MLD snooping provides advanced multicast filtering & network efficiency
- 802.3ad Link Aggregation (LACP) Supports Traffic Load Balancing
- Spanning Tree (STP), Rapid Spanning Tree (RSTP) & Multiple Spanning Tree (MSTP)
- Voice VLAN for fast, reliable deployment of VoIP services
- Features 24 networking ports to meet the requirements of the most demanding workgroups
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Can work as layer 3 routing for scalable network design
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Rack mounting enables you to organize wires & secure cables for professional installation
- Power Source : Power Supply
- Product Series : ECS
- Modular : Yes
- Packaged Quantity : 1
- Form Factor : Rack-mountable,Compact
- Package Contents :
- Cloud Managed 24-Port 13" Compact Gigabit Switch with 4 SFP+ Ports
- 1 x Quick Installation Guide
- 1 x Power Cord
- 1 x RJ45 Console Cable
- 1 x Rack Mount Kit
- Manufacturer Website Address : http://www.engeniustech.com
- Uplink Port : Yes
- Manufacturer : EnGenius Technologies, Inc
- Product Model : ECS1528T
- Compatible Rack Unit : 1U
- Manageable : Yes
- Network Technology : 10/100/1000Base-T,10GBase-X
- Ethernet Technology : Gigabit Ethernet,10 Gigabit Ethernet
- Layer Supported : 3
- Input Voltage : 120 V AC,230 V AC
- Port/Expansion Slot Details : 24 x Gigabit Ethernet Network,4 x 10 Gigabit Ethernet Expansion Slot
- Limited Warranty : 2 Year
- Network (RJ-45) : Yes
- Product Type : Ethernet Switch
- Length : 12.99" (330 mm)
- Number of Total Expansion Slots : 4
- Networking Standards : IEEE 802.1x,IEEE 802.3ad,IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3bz,IEEE 802.3x,IEEE 802.1Q,IEEE 802.1D,IEEE 802.3az
- Total Number of Network Ports : 24
- Media Type Supported : Optical Fiber,Twisted Pair
- Expansion Slot Type : SFP+
- Number of SFP+ Slots : 4
