Description
The ST121SHD50 HDMI® over Cat5e/Cat6 Video Extender kit lets you extend HDMI video and audio by up to 165 feet (50 Meters) over dual Cat5e cables or dual Cat6 cables.For added versatility the kit features Power Over Cable andonly requires asingle power adapter that can be connected to either the Transmitter or Receiver.
With support for High-Definition resolutions of up to 1920x1080 / 1080p and the accompanying digital audio, this cost-effective HD extender can easily be installed using new or existing Ethernet infrastructure wiring. For a convenient plug-and-play installation, the HDMI extender features built-in EDID monitor emulation, which ensures native resolution and maximum compatibility with your display or projector.
For added flexibility and convenience, HDMI cables up to 32ft (10m) can be connected to both the local and remote units, which lets you extend your HDMI signal to even further distances.
The HDMI extender kit offers a point-to-point digital signage solution right out of the box, including both local transmitter and remote receiver units, along with optional hardware that lets you mount the units as needed.Plus, withPowerOverCable, you can easily extend anHDMI signal inareas where access to power outlets is limited.
This product is TAA compliant and backed by a Startech.com 2-year warranty with free lifetime technical support.
- Includes transmitter (local) and receiver (remote) units
- Supports HD resolutions up to 1080p (1920x1080)
- Supports Cat5e or Cat6 Ethernet cabling (50m)
- No software/drivers required
- Power Over Cable allows a single power source to operate the Transmitter and Receiver
- Environmental Certification : RoHS,WEEE,REACH
- Number of HDMI Outputs : 1
- Maximum Operating Distance : 164.04 ft (50000 mm)
- Number of Input Devices Supported : 1
- Transmitter Depth : 3.10" (78.74 mm)
- Number of Output Devices Supported : 1
- Transmitter Weight (Approximate) : 314 g
- Form Factor : Rack-mountable
- Receiver Width : 2" (50.80 mm)
- Manufacturer Website Address : http://www.startech.com
- Package Contents :
- 1 x HDMI over CAT5e/6 UTP Transmitter
- 1 x HDMI over CAT5e/6 UTP Receiver
- 1 x Universal Power Adapter (NA / EU / UK / AU)
- 2 x Mounting Brackets
- 2 x Foot Pad Set
- 1 x Instruction Manual
- HDMI Out : Yes
- Twisted Pair Cable Standard : Category 6
- Manufacturer : StarTech.com
- Receiver Weight (Approximate) : 314 g
- Transmitter Height : 0.80" (20.32 mm)
- Maximum Video Resolution : 1920 x 1080
- TAA Compliant : Yes
- Environmentally Friendly : Yes
- Receiver Height : 0.80" (20.32 mm)
- HDMI In : Yes
- Receiver Depth : 3.10" (78.74 mm)
- Limited Warranty : 2 Year
- Network (RJ-45) : Yes
- Number of HDMI Inputs : 1
- Product Type : Video Extender Transmitter/Receiver
- Graphics Modes : Full HD
- Transmitter Width : 2" (50.80 mm)
- Media Type Supported : Twisted Pair
- Number of Network (RJ-45) Ports : 4
- Country of Origin : Taiwan
- Connectivity Technology : Wired
- Product Color : Black
