DiskStation® DS1823xs+ | Flexible large-scale storage for small and medium-sized businesses
Private data center on your desk
The DS1823xs+ is a powerful central storage server that can easily be deployed anywhere to provide secure data storage and sharing, endpoint and server backup, VM storage, surveillance management, and other business applications. It is perfect in environments where no dedicated server rack or data center is available.
Desktop-sized powerhouse
Over 3,100/2,600 MB/s seq. read/write, built-in 10GbE, and up to 144 TB raw storage before expansion.
Flexible configuration
Add up to 10 extra drive bays, 25GbE or Fibre Channel, and SSD cache volumes when needed.
Versatile applications
Back up 300 endpoints, manage 75 IP cameras, or safely sync and share files between devices and sites.
Safe, dependable, and scalable
Built-in data integrity protection, remote management options, and easy hardware expansion make the DS1823xs+ dependable, easy to maintain, and cost efficient.
Data integrity protection
The Btrfs file system helps prevent data corruption and loss through metadata mirroring, file self-healing, and efficient point-in-time snapshots. ECC memory provides additional integrity safeguards.
Efficient remote management
Monitor, manage, and replace drives and storage online in Synology DiskStation Manager (DSM). Remotely reboot, reset, or view logs while the system is down thanks to out-of-band management (OOB).
Plug-and-play expansion
The DS1823xs+ can be scaled to up to 18 bays by adding two DX517 expansion units without system downtime, thanks to online storage and volume expansion.
The performance you need
Configure the DS1823xs+ to handle any workload. Easily add 1/10/25GbE or Fibre Channel ports and designate NVMe or SATA SSD volumes as read/write cache to boost HDD performance.
Simply faster
Experience faster file indexing and higher sequential throughput with Synology Drive.
Store, share, and protect
Manage all your documents, photos, and other files, back up applications and devices, and protect your physical assets with professional video surveillance.
Flexible file server
Use the DS1823xs+ as a central file repository and data sharing hub. Provide easy access to business data from PCs, phones, and other devices, and set up powerful cross-site syncing to empower collaboration between offices or branches.
Private Cloud | A private cloud suite for file sharing
Empower your entire organization with streamlined ability to access, share, and sync data from anywhere. Provide employees with access to corporate files through mobile apps, desktop clients, and a browser-based interface. Set granular file and folder access and sharing permissions. Maintain a full overview of file activities and track changes to file share settings with detailed records in the Synology Drive Admin
Dependable and secure network storage
Use shared folders on your Synology device as reliable storage available from anywhere on your local network over all common protocols (SMB/NFS/WebDAV/FTP). Protect your files against accidental changes, removal, or even malware attacks with built-in snapshot technology and other backup options.
- Perform computational tasks effectively accrediting the amd ryzen 3.35 ghz processor
- Through RAID levels (0, 1, 5, 6, 10, basic, hybrid raid, jbod), RAID provides data reliability, fault tolerance and improves overall performance
- Up to 10x faster than standard Ethernet connectivity and provides high-performance uplinks
- Protocols : AFP,FTP,iSCSI,NFS,SMB,WEBDAV,SMB 1.0,CIFS,SMB 2.0,SMB 3.0,NFSv3,NFSv4,NFSv4.1,HTTP,HTTPS,SNMP,LDAP,CalDAV
- Maximum Power Supply Wattage : 250 W
- Number of Hard Drives Installed : 0
- Controller Type : Serial ATA
- Product Series : Plus
- Total Number of USB Ports : 3
- Number of USB 3.2 Gen 1 Ports : 3
- Processor Type : Ryzen
- Packaged Quantity : 1
- Processor Core : Quad-core (4 Core)
- RAID Supported : Yes
- Form Factor : Desktop
- Memory Technology : DDR4 SDRAM
- Package Contents :
- DiskStation DS1823XS+ SAN/NAS Storage System
- Power Adapter
- 1 x Accessory Pack
- 1 x AC Power Cord
- 2 x RJ-45 LAN Cable
- 1 x Quick Installation Guide
- Manufacturer Website Address : http://www.synology.com
- Processor Manufacturer : AMD
- eSATA : Yes
- Number of Solid State Drive Installed : 0
- Number of Power Supplies Installed : 1
- Manufacturer : Synology, Inc
- Product Model : DS1823XS+
- Processor Model : V1780B
- Number of Total Expansion Bays : 8
- Operating System : DiskStation Manager
- RAID Levels : 0, 1, 5, 6, 10, Basic, Hybrid RAID, JBOD
- Standard Memory : 4 GB
- Environmental Certification : RoHS
- Ethernet Technology : Gigabit Ethernet,10 Gigabit Ethernet
- Number of Hard Drives Supported : 8
- Environmentally Friendly : Yes
- Additional Warranty Information :
The DS1823xs+ is backed by Synology's 5-year limited warranty
- Number of 2.5"/3.5" Bays : 8
- Number of Solid State Drive Supported : 8
- Limited Warranty : 5 Year
- Processor Speed : 3.35 GHz
- Network (RJ-45) : Yes
- Product Type : SAN/NAS Storage System
- Number of Total Expansion Slots : 1
- Number of Network (RJ-45) Ports : 3
- Product Line : DiskStation
- Expansion Slot Type : PCI Express 3.0 x8
