Description
-
Frequency Range
617 ~ 960, 1700 ~ 2700, 3300 ~ 4300 MHz
-
Polarisation
Vertical
-
Radiation pattern type
Omnidirectional
-
Gain
Max 4.5 dBi
-
V.S.W.R
< 2.50
-
Impedance
50 Ω
-
Connector type and count
4x SMA male
-
Frequency Range
1560 ~ 1610 MHz
-
Polarisation
RHCP
-
Gain
28 dBi
-
V.S.W.R
< 2.00
-
Impedance
50 Ω
-
Connector type and count
1x SMA male
-
Current consumption
2.5 - 6.5 mA
-
Supply voltage
2.5 - 6.5 VDC
-
Frequency Range
2400 ~ 2500, 4700 ~ 6000 MHz
-
Polarisation
Vertical
-
Radiation pattern type
Omnidirectional
-
Gain
Max 7.5 dBi
-
V.S.W.R
< 2.00
-
Impedance
50 Ω
-
Connector type and count
2x RP-SMA male
-
Cable
6x RG316, 1x RG174
-
Operating Temperature
-40 °C to 75 °C
-
Mounting Method
Wall, ceiling, mast
-
IP rating
IP67
-
Weight
1500 g
-
RoHS compliant
✓
