Description
The desktop B004-DPUA2-K 2-Port DisplayPort KVM Switch lets you access, control, boot and reboot two DisplayPort computers using one DisplayPort monitor, USB keyboard and USB mouse. Switching between DisplayPort computers is quick and simple using keyboard hotkeys or buttons on the unit.
You can also plug microphones and speakers into the 3.5 mm mini-stereo jacks, and the two-port USB 3.0 SuperSpeed hub allows you to connect peripherals, such as a webcam, flash drive, printer or scanner, and share them with both computers. Because the audio and USB 3.0 hub ports can be accessed independently, you can, for instance, use a printer connected to the hub to print data from one computer while also listening to music from the other computer.
All necessary cables are included. The B004-DPUA2-K supports digital video resolutions up to 2560 x 1600 (including 1080p), 2-channel stereo audio and data transfer rates up to 5 Gbps. The built-in DDC emulator sends the console monitor's EDID information to all connected computers to ensure top video quality and prevent any delay or change in video resolution when switching computers.
The B004-DPUA2-K is easy to set up with no software to install and supports Windows, Mac, Linux and Sun. The USB 3.0 hub is backward-compatible with USB 2.0 and USB 1.1 devices.
You can also plug microphones and speakers into the 3.5 mm mini-stereo jacks, and the two-port USB 3.0 SuperSpeed hub allows you to connect peripherals, such as a webcam, flash drive, printer or scanner, and share them with both computers. Because the audio and USB 3.0 hub ports can be accessed independently, you can, for instance, use a printer connected to the hub to print data from one computer while also listening to music from the other computer.
All necessary cables are included. The B004-DPUA2-K supports digital video resolutions up to 2560 x 1600 (including 1080p), 2-channel stereo audio and data transfer rates up to 5 Gbps. The built-in DDC emulator sends the console monitor's EDID information to all connected computers to ensure top video quality and prevent any delay or change in video resolution when switching computers.
The B004-DPUA2-K is easy to set up with no software to install and supports Windows, Mac, Linux and Sun. The USB 3.0 hub is backward-compatible with USB 2.0 and USB 1.1 devices.
- Includes all necessary DisplayPort, USB 3.0 and audio cables
- Supports digital video resolutions up to 2560 x 1600
- Supports USB 3.0 data transfer rates up to 5 Gbps
- Connect peripherals to built-in 2-port USB 3.0 hub
- Switch between computers via front buttons or keyboard hotkeys
- Maximum Video Resolution : 2560 x 1600
- Environmentally Friendly : Yes
- USB : Yes
- Number of Computers Supported : 2
- Limited Warranty : 3 Year
- Package Contents :
- 2-Port DisplayPort KVM Switch w/Audio, Cables and USB 3.0 SuperSpeed Hub
- 2 x DisplayPort Cables, 4 ft.
- 2 x USB 3.0 Type-A to Type-B cables, 4 ft.
- 2 x 3.5 mm mini-stereo cables, 4 ft.
- External Power Supply (Input: 100/240V, 50/60 Hz, 0.5A; Output: 9V, 2A)
- Universal Plug Adapters (NEMA 1-15P, CEE 7/16, BS1363, and AS3112)
- Owner's Manual
- Number of USB Ports : 6
- Number of DisplayPorts : 3
- Product Type : KVM Switchbox
- DisplayPort : Yes
- Manufacturer : Tripp Lite by Eaton
- Product Model : B004-DPUA2-K
- Country of Origin : China
- Number of Local Users Supported : 1
- Manufacturer Website Address : https://tripplite.eaton.com/
