Description
Tripp Lite B130-202A Allows You To Extend Two 1024X768 Vga Video Signals + Stereo Audio Up To 500 Ft., Over Ordinary Cat5E Cable, From A Single Vga+Audio Source. The Transmitter / Receiver Kit Also Features Two Local Vga Hd15 Ports, Supporting A Total Of Four Vga Monitors ( 2 Local And 2 Remote ). Compatibility Issues Can Occur When Edid Information Is Not Properly Communicated Between The Source And The Display. The B130-202A Includes An Edid Copy Feature Which Stores A Monitor'S Edid Information In The Transmitter And Sends It To The Source, Ensuring Optimal Compatibility. Supports All Operating Systems, And Is Plug-And-Play...No Software Or Drivers Are Required.
- EDID copy feature ensures optimal display compatibility
- Extends a VGA + Stereo Audio signal up to 500 ft.
- Connect up to four VGA monitors: 2 Local and 2 Remote
- Number of VGA Inputs : 1
- Maximum Video Resolution : 1920 x 1440
- TAA Compliant : Yes
- Number of VGA Outputs : 4
- Maximum Operating Distance : 500 ft (152400 mm)
- Number of Input Devices Supported : 1
- Transmitter Depth : 2.44" (61.98 mm)
- Limited Warranty : 1 Year
- Number of Output Devices Supported : 2
- Package Contents :
- B130-202A Transmitter Unit
- B130-202A Receiver Unit
- 2 x External Power Supplies (Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A)
- Screwdriver For Equalization Adjustment
- Owner's Manual
- VGA In : Yes
- Network (RJ-45) : Yes
- Product Type : Video Extender Transmitter/Receiver
- Twisted Pair Cable Standard : Category 6
- Manufacturer : Tripp Lite by Eaton
- Product Model : B130-202A
- Transmitter Height : 1.06" (26.92 mm)
- Transmitter Width : 4.50" (114.30 mm)
- VGA Out : Yes
- Media Type Supported : Twisted Pair
- Country of Origin : Taiwan
- Number of Network (RJ-45) Ports : 2
- Connectivity Technology : Wired
- Manufacturer Website Address : https://tripplite.eaton.com/
