Description
USB-C Adapter Turns Your Device's USB-C or Thunderbolt 3 Port into a Multiport Workstation
This versatile 8K adapter adds multiple ports to the USB-C or Thunderbolt 3 port on your MacBook Pro, Windows laptop or Chromebook. The U442-DOCK40-6 allows you to transmit digital audio and 8K video to an external display, add USB peripherals, connect to a Gigabit Ethernet network, and power and charge a PD Charging-compliant host device simultaneously. It is ideal for future-proofing your high-definition or Ultra HD application in anticipation of an 8K upgrade.
Supports USB-C DisplayPort Alternate Mode for Transmitting Audio/Video Signals
By connecting the built-in USB-C cable to a source device that supports USB DisplayPort Alt Mode, you can output 8K video and digital audio to a compatible HDMI monitor, television or projector without installing special software drivers.
Enjoy the Clarity of 4K/8K Video with Multi-Channel Audio, HDR and 4:4:4 Color
The HDMI port supports 8K UHD resolutions up to 7680 x 4320 at 30 Hz for professional photo and video editing. It also supports High Dynamic Range (HDR10+), providing a wide range of vibrant colors with richer contrast, brighter whites and deeper blacks. HDCP 2.3 compliance allows you to stream 4K content with no complications. This adapter also supports 4:4:4 chroma subsampling for top-level PC gaming or using your HDTV as a PC monitor.
Connects USB Peripherals and Transfers Data at Fast USB 3.2 Gen 2 Speeds
Three USB 3.2 Gen 2 ports accept USB peripherals, such as flash drives, mice, keyboards and printers. They support lightning-fast data transfer rates up to 10 Gbps and are backward compatible with USB 2.0 and USB 1.1 devices. One USB-A port and the USB-C port provide up to 5V/1.5A (7.5W) of charging power to mobile devices. The other USB-A port provides 5V/0.9A (4.5W) to connected devices. The three ports support over-current, over-voltage, over-temperature and short circuit protection.
PD 3.0 Charging Port Charges High-Powered Devices via AC Wall Charger
The USB-C Power Delivery port provides power output up to 20V 5A (100W), which is sufficient for charging and powering the connected source device, such as a MacBook or Chromebook. Just connect the device's AC wall charger to the USB-C PD port.
Accesses a Wired Gigabit Ethernet Network
The dedicated RJ45 port offers access to a Gigabit Ethernet network when Wi-Fi is unavailable or when a wired connection offers faster speeds. Connect using a UTP cable (sold separately), and enjoy true 10/100/1000 Mbps Ethernet speeds for fast web browsing.
Ready to Use Right from the Package, So You Can Plug and Play Immediately
The plug-and-play USB-C multiport adapter is specifically designed for the MacBook Pro, Windows laptops and other notebooks, smartphones, tablets and devices equipped with a USB-C or Thunderbolt 3 port. It requires no extra software to be downloaded or installed. Its thin profile design fits easily into a pocket, purse or laptop bag for convenient connections on the go.
. .- Number of Displays Supported : 1.0
- USB Power Delivery : 100W
- USB Type-C Detail : 1 x USB-C - USB 3.2 Gen 2 (10 Gbps)
- Number of RJ-45 Ports : 1
- Device Supported : TV/Monitor/Notebook/Keyboard/Mouse/Smartphone/Tablet/Desktop PC/Projector/Flash Drive
- Total Number of USB Ports : 4
- USB Type-C : Yes
- Package Contents :
- U442-DOCK40-6 Docking Station
- Owner's Manual
- Manufacturer Website Address : https://tripplite.eaton.com/
- Operating System Supported : Windows
- Screen Mode Supported : 8K,4K,5K,Full HD,HD
- DisplayPort : Yes
- USB Type-A : Yes
- Manufacturer : Tripp Lite by Eaton
- Product Model : U442-DOCK40-6
- Supported Resolutions : 7680 x 4320,3840 x 2160,5120 x 2880,1920 x 1080,1280 x 720
- Environmental Certification : REACH,RoHS 3,WEEE
- Ethernet Technology : Gigabit Ethernet
- Environmentally Friendly : Yes
- Number of USB Type-A Ports : 2
- Product Color : Gray
- Limited Warranty : 1 Year
- DisplayPort Version : 1.4
- Number of USB 3.2 Gen 2 Type-A Ports : 2
- Network (RJ-45) : Yes
- Number of HDMI Ports : 1
- Host Interface : USB Type C
- Product Type : Docking Station
- HDMI : Yes
- Compatibility :
- MacBook Pro
- MacBook
- Chromebook
- Connectivity Technology : Wired
- Number of USB Type-C Ports : 2.0
