Description
Tripp Lite Basic Power Distribution Units give IT Managers the ability to power multiple servers and vital networking hardware from a single input power source. Switch-free unfiltered electrical pass-through reliably distributes UPS or generator power to critical equipment in rack enclosures, network closets and more. Tooless mounting enables simple installation in button-mount compatible racks. Included mounting brackets support vertical installation in standard 2 and 4 post racks or other surfaces, such as under-counter or wallmount configurations. Plug retention brackets keep vital equipment plugged in and continuously powered.PDUV30HV 63.75 in. vertical 0U rack PDU supports 30A maximum capacity at 208/240V (agency derated to 24A). Includes 10 ft. attached line cord with L6-30P input plug. 32 C13 and 6 C19 outlets support up to 38 directly connected pieces of networking equipment. Outlets are arranged in two separately breakered 15A load banks.
- Toolless button-mount installation
- Cord retention brackets keep vital equipment plugs connected
- 38 total output receptacles (6 C19, 32 C13)
- 10 ft. input cable with locking L6-30P plug
- 208/240V 30A maximum capacity
- Basic 0U 63.75 in. vertical rack PDU
- Receptacle Type : IEC 60320 C19,IEC 60320 C13
- Receptacle Detail : 6 x IEC 60320 C19,32 x IEC 60320 C13
- PDU Type : Basic
- Input Voltage : 230 V AC
- Limited Warranty : 5 Year
- Package Contents :
- PDUV30HV PDU Basic 208V - 240V 30A 38 Outlet
- PDUV30HV 63.75 inch basic PDU with owner's manual
- Set of 2 plug retention brackets and installation hardware
- Set of mounting brackets and installation hardware
- Plug/Connector Type : NEMA L6-30P
- Product Type : PDU
- Mount Type : Wall-mountable,Rack-mountable
- Protection Type : Overload Protection,Short Circuit Protection
- Manufacturer : Tripp Lite by Eaton
- Product Model : PDUV30HV
- Input Voltage Range : 208 V AC - 240 V AC
- Output Voltage : 208 V AC,240 V AC
- Mounting Orientation : Vertical
- Country of Origin : China
- Manufacturer Website Address : https://tripplite.eaton.com/
