Description
Tripp Lite's line-interactive SMART5000RT3U UPS System protects server, networking or telecommunications equipment from blackouts, voltage fluctuations and surges in a compact tower/rackmount housing. Large capacity 5000VA/4000W power module converts raw 208V AC input to fully regulated dual output 208/120 voltage for simultaneous protection of both high- and low-voltage equipment loads. True sine wave output at all times offers guaranteed compatibility with all equipment types. Includes 14 outlets, 8 of which can be individually reset via software interface to selectively reboot remote equipment or shed less critical loads to extend battery runtime for more critical equipment. Includes slot for internal SNMP/web card, plus two DB9 and two USB enhanced monitoring ports for unattended shutdown, remote control and monitoring of UPS system and power data. 2 Year Warranty standard. 3 Year Warranty with product registration.
- Expandable runtime; 8 single-outlet switched output load banks
- NEMA L6-30P input; 10 5-15R, 2 5-15/20R, 1 L6-30R & 1 L14-30R outlets
- USB, Serial, EPO & optional SNMP/Web card monitoring options
- 208 & 120V output during brownouts to 151V and overvoltages to 260V
- 5kVA / 5000VA / 4000W line interactive 6U rack/tower UPS; Sine wave output
- Receptacle Type : NEMA 5-20R,NEMA L14-30R,NEMA 5-15R,NEMA L6-30R
- Receptacle Detail : 2 x NEMA 5-20R,1 x NEMA L14-30R,10 x NEMA 5-15R,1 x NEMA L6-30R
- Input Voltage : 220 V AC
- Transfer Time : 4 ms
- Limited Warranty : 3 Year
- Typical Battery Recharge Time : 4 Hour
- Waveform Type : Sine Wave
- Package Contents :
- SMART5000RT3U UPS
- SMART5000RT3U UPS System
- BP48V60RT3U battery pack
- PowerAlert Software and cabling
- Mounting hardware
- Instruction manual with warranty information
- Backup/Run Time (Full Load) : 16 Minute
- Battery Life : 6 Year
- Plug/Connector Type : NEMA L6-30P
- Product Type : Line-interactive UPS
- Load Capacity : 5 kVA/4 kW
- Battery Chemistry : Lead Acid
- Manufacturer : Tripp Lite by Eaton
- Product Model : SMART5000RT3U
- Hot Swappable : Yes
- Output Voltage : 208 V AC
- Backup/Run Time (Half Load) : 38 Minute
- Rack Height : 6U
- Country of Origin : China
- Product Line : SmartPro
- Network Management : SNMP Manageable
- Maximum Operating Temperature : 104°F (40°C)
- USB : Yes
- Alarm : On Battery,Overload,Low Battery
- Status Indicators : 5 front panel LEDs - Green 5 front panel LEDs - Green POWER LED, Green VOLTAGE CORRECTION LED, 3 color BATTERY CHARGE LED, 3 color OUTPUT LOAD LED, red BATTERY WARNING LED
- Manufacturer Website Address : https://tripplite.eaton.com/
- Cord Length : 10 ft
