Description
60-Bay Hybrid Storage Platform | The Next Generation Hybrid Platform for SoftwareDefined Storage
This new platform addresses the demanding storage needs of large enterprise customers, storage OEMs, cloud service providers and resellers/integrators that require dense, shared HDD or hybrid storage. The Ultrastar Data60® Hybrid Storage Platform provides the flexibility to specify the HDD and SSD combinations to balance capacity, performance and cost.
Designed for Big Data
Conventional dense disk shelves frequently suffer from performance degradation due to induced vibration from adjacent drives. Traditional platforms also have cooling challenges as the cooling air passes over successive rows of drives, losing effectiveness as it gets heated up along the airflow path. Developing storage devices and platforms side-by-side, we address these challenges through vertical innovation, a set of technologies developed based on a holistic view of devices, platform, and their interactions. The first two of these patented technologies are IsoVibe™ and ArcticFlow™. IsoVibe reduces vibration-induced performance degradation, while ArcticFlow overcomes the cooling issues by introducing cool air into the middle of the platform. Both these technologies contribute to long-term reliability, enabling our five-year limited warranty on the entire platform.
Building on 50+ Years of Storage Design Experience
Conventional dense disk shelves frequently suffer from performance degradation due to induced vibration from adjacent drives. Traditional platforms also have cooling challenges as the cooling air passes over successive rows of drives, losing effectiveness as it gets heated up along the airflow path. Developing storage devices and platforms side-by-side, we address these challenges through vertical innovation, a set of technologies developed based on a holistic view of devices, platform, and their interactions. The first two of these patented technologies are IsoVibe™ and ArcticFlow™. IsoVibe reduces vibration- induced performance degradation, while ArcticFlow overcomes the cooling issues by introducing cool air into the middle of the platform. Both these technologies contribute to long-term reliability, enabling our five-year limited warranty on the entire platform.
Designed for the Enterprise and the Cloud
This new platform addresses the demanding storage needs of large enterprise customers, storage OEMs, cloud service providers and resellers/integrators that require dense, shared HDD or hybrid storage. The Ultrastar Data60 provides the flexibility to specify the HDD and SSD combinations to balance capacity, performance and cost.
- Provides amazing solution for expanding PC storage
- Ensures convenient and safe installation with rack mounting facility
- Manufacturer Website Address : http://www.westerndigital.com
- Total Hard Drive Capacity Installed : 72 TB
- Number of Hard Drives Supported : 60
- TAA Compliant : No
- Number of 3.5" Bays : 60
- Number of Solid State Drive Supported : 24
- Cooling Fan : Yes
- Form Factor : Rack-mountable
- Host Interface : 12Gb/s SAS
- Product Type : Drive Enclosure
- Number of Solid State Drive Installed : 0
- Manufacturer : Western Digital Corporation
- Number of Total Expansion Bays : 60
- Rack Height : 4U
- Product Line : Ultrastar Data60
- Drive Interface : 12Gb/s SAS
